Edge Closed Ss Wire Mesh Stainless Steel Wire Mesh SUS304 ISO And SGS

Edge Closed Ss Wire Mesh Stainless Steel Wire Mesh SUS304 ISO And SGS
Edge Closed Ss Wire Mesh Stainless Steel Wire Mesh SUS304 ISO And SGS

Large Image :  Edge Closed Ss Wire Mesh Stainless Steel Wire Mesh SUS304 ISO And SGS

Product Details:

Place of Origin: Hebei, China
Brand Name: Qijie
Certification: ISO, SGS
Model Number: ss-05

Payment & Shipping Terms:

Minimum Order Quantity: 10 rolls
Price: USD 50-400/roll
Packaging Details: Water-proof paper, Plastic bag, wooden cases
Delivery Time: 10-15 working days
Payment Terms: 30%TT
Supply Ability: 500 rolls/month
Detailed Product Description
Technique: Woven Application: Woven Wire Mesh,Filters
Type: Weave Wire Mesh,Wire Cloth,Crimped Wire Mesh Material: Stainless Steel Wire,316,304
Weave Style: Plain Weave,twill Weave,Dutch Weave Product Name: 5 Micron 316L 2500 Mesh Stainless Steel Woven Wire Mesh,304 316L Plain SS Stainless Steel Woven Wire Mesh Disc.
Color: Silver Wire Diameter: 0.010 To 1.20mm
Hole Shape: Square Hole Length: 30m Per Roll Or As Required
High Light:

stainless steel woven mesh


stainless woven mesh

Edge Closed SS Wire Mesh stainless steel wire mesh SUS304 woven wire mesh



1.Through ISO9001:2000
3.Stainless steel wire mesh
4.302stainless wire mesh

stainless steel wire mesh

Material From first class stainless steel wire materials in 304,304L,316,316L.
ProceduresPlain weave, twill weave, dutch weave.
CharacteristicsStainless Steel is selected for their wear-resisting, heat-resisting, acid-resisting and corrosion resisting characteristics.
Applications uses in processing of oils, chemicals, food, pharmaceuticals, also sorting and screening of solid, liquid and gas in mine, metallurgy, airspace, machine making, etc.
We can produce all kinds of stainless steel wire mesh, including stainless steel square wire mesh and stainless steel twilled woven mesh. Stainless steel wire mesh with its anti-wearing, heat resistance, acid resistance and anti-corrosion properties, is used popularly for mining, chemical industry, food industry, the pharmaceutical industry and many other fields.


Material SS wire 201,304,316,316L
Wire diameter 0.018-2.03mm
Woven type plain weave,twill weave,dutch weave,reversed dutch weave,crimped weave
Mesh counts

plain weave wire mesh can be woven up to 400 mesh

twill weave wire mesh can be woven from 30 to 635 mesh



Twill Weave Dutch Mesh


Mesh (mesh/inch)

Warp x Weft
Warp x Weft (mm) Aperture Size (um)
20x270 0.25x0.2 119
20x200 0.35x0.28 118
24x300 0.28x0.18 110
20x150 0.45x0.355 101
30x340 0.28x0.16 89
30x270 0.28x0.20 77
40x540 0.18x0.10 70
40x430 0.18x0.125 63
50x600 0.125x0.09 51
50x500 0.14x0.11 47
65x600 0.14x0.09 36
70x600 0.14x0.09 31
78x760 0.112x0.071 31
78x680 0.112x0.08 29
80x680 0.112x0.08 28
90x850 0.10x0.063 26
90x760 0.10x0.071 24
100x850 0.10x0.063 22
130x1500 0.063x0.036 21
100x760 0.10x0.071 20
130x1200 0.071x0.045 18
130x1100 0.071x0.05 17
150x1400 0.063x0.04 15
160x1500 0.063x0.036 15
165x1500 0.063x0.036 14
174x1700 0.063x0.032 13
165x1400 0.063x0.04 13
174x1400 0.063x0.04 11
203x1600 0.05x0.032 10
216x1800 0.045x0.03 10
203x1500 0.056x0.036 9
250x1900 0.04x0.028 8
250x1600 0.05x0.032 8
285x2100 0.036x0.025 7
300x2100 0.036x0.025 6
317x2100 0.036x0.025 5
325x2300 0.036x0.024 4
363x2300 0.032x0.022 4
400x2700 0.028x0.02 4
500x3500 0.025x0.015 3

Edge Closed Ss Wire Mesh Stainless Steel Wire Mesh SUS304 ISO And SGS 0


1. Q: Are you a factory or trading company?
A: We are a factory.

2. Q: What certificate do you have?
A: We have ISO and CE certificate.
3. Q: How does your factory do regarding quality control?
A: We have a special QC department in charge of products’ quality.
4. Q: How long is the warranty period?
A: All of our products have one year warranty.
5. Q: What’s the main market of your company?
A: We have customers all over the world.
6. Q: How much production capacity of your company one year?
A: This depends on your needs.
7. Q: Where is your factory located? How can we visit there?
A: Our factory is located in Anping county,Hengshui City, Hebei, China,
Near Shijiazhuang Airport and Beijing Airport. We offer transportation service.
