Quarry / Stone Crusher Crimped Sand Vibrating Screen 1.5*2M Size Wear Proof

China Quarry / Stone Crusher Crimped Sand Vibrating Screen 1.5*2M Size Wear Proof supplier

Large Image :  Quarry / Stone Crusher Crimped Sand Vibrating Screen 1.5*2M Size Wear Proof

Product Details:

Place of Origin: Hebei, China
Brand Name: XMESH
Certification: SGS
Model Number: 3mm

Payment & Shipping Terms:

Minimum Order Quantity: 200pcs
Packaging Details: pallets
Delivery Time: 15-25days
Payment Terms: 30%TT in advance, Balance Before loading
Supply Ability: 100pieces per week
Contact Now
Detailed Product Description
Material: High Tensile Steel Wire Aperture: 3mm
Size: 1.5mx2m Install: Hooked
Use: Quarry And Stone Crusher Feature: Tough Structure

Quarry and Stone Crusher Crimped Vibrating Screen Mesh 1.5*2M



Middle Carbon Steel Mining Screen is widely used in industry for filtration, separation, crushing, grading, sizing and shifting. It is applicable for a variety of materials, ranging from minerals, stones and ores. Due to its rigid design and excellent protection against abrasions, it is highly suitable for processing heavy abrasive materials like crushed stones, sand and gravel coal.

Material:

  • Carbon steel wire(high carbon steel,middle carbon steel,low-carbon steel)
  • Stainless steel wire (302,304,304L,316,316L)
  • Galvanized wire copper
  • Copper wire

Features:

  • Heavy duty design-
  • Tough structure
  • Corrosion resistant
  • Abrasion resistant
  • Wear proof

Applications:

  • Mining industry
  • coal factory
  • quarry
  • sieving
  • grading
  • separating screening materals

Used for:

  • Sizing
  • Classification

Weaving Types:

Double Crimp Screen of Crimped Wire MeshDouble Crimp Screen of Crimped Wire Mesh


Egdy Types:

Double Crimp Screen of Crimped Wire Mesh
Packing:

  • rolls/panels wrapped with waterproof paper then covered with hessian-cloth .
  • water-proof paper and wooden pallet/box
  • according to request.
Item Wire diameter
Mm
Open size
Mm
Width
M
Length
M
Weight
Kg
1 2 3 1.5 2 32
2 3 5 1.5 2 42.6
3 4 8 1.5 2 51.13
4 4.5 12 1.5 2 46.77
5 5 16 1.5 2 45.52
6 5.5 18 1.5 2 49.37
7 6 20 1.5 2 52.7
8 6 22 1.5 2 48.96
9 6.5 24 1.5 2 52.87
10 6.5 27 1.5 2 48.12
11 7 30 1.5 2 50.63
12 8 50 1.5 2 42.29
13 12 75 1.5 2 64

Our woven wire mesh is manufactured with a stringent wire opening tolerance of ±3%.Wire diameter is available in the industrys largest variety of wire diameters from .047 inches(1.2mm) to .750 inches(19 mm) and open size from .125 inches (3.18mm)to 5 inches (127mm)
