Customized Stainless Steel Woven Wire Mesh 201 304 304L 316 316L 431 321 347 SS

Certification
China Hebei Qijie Wire Mesh MFG Co., Ltd certification
China Hebei Qijie Wire Mesh MFG Co., Ltd certification
Customer Reviews
Yes we have received the reinforcing mesh and we are pretty happy with the quality. Many thanks! Chris

—— Chris Johnson

I have been ordering powder coated T 316 fly screen mesh from Qijie; unlike others, they never cut orders and always supply quality material to me.

—— Michael Jr. Venida

I had very bad purchasing experience with the previous supplier, for they always postpone shipment time. To my excitement, Qijie is always punctual.

—— Susan Miller

Your product good

—— Jatuporn Tae-Ngug

I'm Online Chat Now

Customized Stainless Steel Woven Wire Mesh 201 304 304L 316 316L 431 321 347 SS

Customized Stainless Steel Woven Wire Mesh 201 304 304L 316 316L 431 321 347 SS
Customized Stainless Steel Woven Wire Mesh 201 304 304L 316 316L 431 321 347 SS Customized Stainless Steel Woven Wire Mesh 201 304 304L 316 316L 431 321 347 SS Customized Stainless Steel Woven Wire Mesh 201 304 304L 316 316L 431 321 347 SS Customized Stainless Steel Woven Wire Mesh 201 304 304L 316 316L 431 321 347 SS Customized Stainless Steel Woven Wire Mesh 201 304 304L 316 316L 431 321 347 SS

Large Image :  Customized Stainless Steel Woven Wire Mesh 201 304 304L 316 316L 431 321 347 SS

Product Details:
Place of Origin: Hebei, China
Brand Name: Qijie
Certification: ISO, SGS
Model Number: ss-09
Payment & Shipping Terms:
Minimum Order Quantity: 10 rolls
Price: USD 50-400/roll
Packaging Details: Water-proof paper, Plastic bag, wooden cases
Delivery Time: 10-15 working days
Payment Terms: 30%TT in advance, Balance before loading
Supply Ability: 500 rolls/month
Detailed Product Description
Technique: Woven Application: Woven Wire Mesh,Filters
Type: Weave Wire Mesh,Wire Cloth,Crimped Wire Mesh Material: Stainless Steel Wire,316,304
Weave Style: Plain Weave,twill Weave,Dutch Weave Product Name: 5 Micron 316L 2500 Mesh Stainless Steel Woven Wire Mesh,304 316L Plain SS Stainless Steel Woven Wire Mesh Disc.
Color: Silver Wire Diameter: 0.010 To 1.20mm
Hole Shape: Square Hole Length: 30m Per Roll Or As Required
Usage: Liquid Filter,chmical Industry,oil,filtration,filtering And Sieveing Width: 0.5m-3m Or Customized
Feature: Corrosion Resistance,Anti-corrosion,alkali-resisting Etc Mesh Count: 2-650mesh
Mesh: 1-2300 Name: 304 316 20Mesh Plain Woven Stainless Steel Wire Mesh,Stainless Steel Square Wire Mesh Woven Aluminum Wire Mesh
Sample: Avaliable
High Light:

stainless steel woven mesh

,

stainless woven wire mesh

customized 201 304 304L 316 316L 431 321 347 304 ss 316 stainless steel wire mesh woven wire mesh


Stainless steel :Stainless steel is selected for their wear-resisting, heat-resisting, acid-resisting and corrosion resisting characteristics. Many different grades of stainless are used in wire cloth.T304 is the most common, but other are used in specific applications to take advantage of each grade’s unique properties. The wire mesh made of stainless steel is extensively used in mining , chemical industry, food industry and pharmaceutical industry.



Material: SS wire 201, 304, 304L, 316, 316L, 431, 321 347 etc.
Wire diameter: 0.018-2.03mm
Woven style: plain weave,twill weave,dutch weave,reversed dutch weave,crimped weave
Mesh counts: Plain weave wire mesh can be woven up to 400 mesh.
Twill weave wire mesh can be woven from 30 to 635 mesh.
Packaging Details: inner kraft, outside plastic cloth, put into wooden pallet or case





Specifications
Type Mesh/Inch Wire diameter
(inch)
OPen Area Weight (LB)
/100 Square Foot
Plain,Twill Wire Mesh 1 × 1-635 × 635 0.0008"-0.08" 25 to 84.6 2.53 to 41.1
Type Mesh/Inch Wire diameter
(inch)
Absolute Filtration
Finess μm
Nominal Filtration
Finess μm
Plain Dutch Weave
Wire Mesh
8 × 85 - 80 × 400 0.014'' × 0.0126''- 0.0049'' × 0.0028'' 318-340 to 43-48 250-255 to 35-40
Twill Dutch Weave
Wire Mesh
20 × 250 - 500 × 3200 0.0098'' × 0.0079'' - 0.0015'' × 0.0010'' 110-120 to 8-9 98-105 to 2-3

Uses: Mainly used for Separation and Flitration, extensively used in petroleum, chemical industry, enviroment protection,mine, airspace, paper-making, electronic, metallurgy etc.



We can produce all kinds of stainless steel wire mesh, including stainless steel square wire mesh and stainless steel twilled woven mesh. Stainless steel wire mesh with its anti-wearing, heat resistance, acid resistance and anti-corrosion properties, is used popularly for mining, chemical industry, food industry, the pharmaceutical industry and many other fields.




Customized Stainless Steel Woven Wire Mesh 201 304 304L 316 316L 431 321 347 SS 0
Customized Stainless Steel Woven Wire Mesh 201 304 304L 316 316L 431 321 347 SS 1

Q&A:


1. Q: Are you a factory or trading company?
A: We are a factory.

2. Q: What certificate do you have?
A: We have ISO and CE certificate.
3. Q: How does your factory do regarding quality control?
A: We have a special QC department in charge of products’ quality.
4. Q: How long is the warranty period?
A: All of our products have one year warranty.
5. Q: What’s the main market of your company?
A: We have customers all over the world.
6. Q: How much production capacity of your company one year?
A: This depends on your needs.
7. Q: Where is your factory located? How can we visit there?
A: Our factory is located in Anping county,Hengshui City, Hebei, China,
Near Shijiazhuang Airport and Beijing Airport. We offer transportation service.
