AISI 304 Compressed Knitted Metal Wire Mesh Discs / Baskets / Strainers / Cylinders

China AISI 304 Compressed Knitted Metal Wire Mesh Discs / Baskets / Strainers / Cylinders supplier
AISI 304 Compressed Knitted Metal Wire Mesh Discs / Baskets / Strainers / Cylinders supplier AISI 304 Compressed Knitted Metal Wire Mesh Discs / Baskets / Strainers / Cylinders supplier AISI 304 Compressed Knitted Metal Wire Mesh Discs / Baskets / Strainers / Cylinders supplier AISI 304 Compressed Knitted Metal Wire Mesh Discs / Baskets / Strainers / Cylinders supplier

Large Image :  AISI 304 Compressed Knitted Metal Wire Mesh Discs / Baskets / Strainers / Cylinders

Product Details:

Place of Origin: China
Brand Name: Qijie
Certification: SGS
Model Number: QJKM

Payment & Shipping Terms:

Minimum Order Quantity: 1000pcs
Packaging Details: wood case or paper carton
Delivery Time: 15-18days
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability: 10000pcs
Contact Now
Detailed Product Description
Material: Stainless Steel | Aluminum | Brass | Carbon Steel | Galvanized Steel | Monel Filtration Rating: 2micron-2000micron
Use: - Filter Discs - Filter Baskets,Strainers,Cylinders - Filter Cones - Filter Anchor Mesh Sleeves - Filter Dixon Rings Application: Filters,Woven Wire Mesh
Weave Style: Plain Weave,Dutch Weave,Twill Weave Technique: Woven,Weave
Product Name: Sus304 Stainless Steel Wire Mesh,stainless Steel Woven Metal Mesh Wire Diameter: Requirement,0.03-5mm
Usage: Filter,Construction,filtration Feature: Corrosion Resistance,beautiful,durable,Easily Assembled,good Drooping


AISI 304 Compressed Stainless Steel Knitted Mesh Discs, Baskets,Strainers,Cylinders


Compressed galvanized knitted mesh filter element
Material: galvanized steel wire.
Compressed knitted thickness 8 mm: 0.3mm.
Free volume: 85% ± 3%.
Filter diameter: 29mm ± 0.2mm.
Thickness: 9.5mm ± 0.2mm.

Compress knitted mesh rings for emission control systems
Materials: stainless steel 1.4404.
Wire diameter is 0.18 mm.
Outer diameter is 285 +/- 0.5 mm.
Inner diameter is 272 +/- 0.5mm.
Thickness is 10 +/- 0.5.
Density is 0.69g/cc.

Knitted wire mesh seal for diesel particulate filter axial load absorber purpose
Outer diameter: 300.3 mm.
Inner diameter: 267.8 mm.
Compressed knitted thickness: 8 mm.

Compressed knitted mesh filter- Stainless steel AISI 304
Wire diameter: 0.15 mm to 0.6 mm.
Diameter: 28 mm.
Thickness: 40 mm.

Compressed Knitted mesh pad - AISI 316L
Wire diameter: 0.25 mm.
Density: 205.46 kg/m3.
Volume: Option A: 8.459 m3, Option B: 5.623 m3.

Knitted wire mufflers for heat shield at the catalytic converter. (Gasoline)
D_outer:15 mm.
D_inner:10 mm.
Width: 5 mm.

Engine inlet pre filters
Knitted wire mesh pre filters for an engine going in a desert environment.
Size: 530 mm × 335 mm.
Thickness up to 20 mm.

Compressed knitted mesh filter is always customized for specific application. Different thickness, wire diameter, density mean different filtration effects. So it is hard to say which one is standard. Thus, there is no standard size for them, but customized one can meets your needs well. And we are sure our products will not let you down.

Product name Knitted Mesh Exhaust Silencers
Material SS304, SS316, brass wire
Technique compressed knitted
Wire diameter 0.03mm to 0.5mm
Circle Diameter 1cm to 7cm and customized
Thickness 2mm to 25mm and customized
Feature

High strength and overall rigidity
Good air permeability
Excellent filtering accuracy
Good filter resistance, mechanical strength, abrasion resistance, heat resistance and cold resistance Easy to clean, simple assembly, long replacement cycle.
Special sizes can be customized.

Application Used for oil-gas separation, air purification filters of various machinery and equipment. Sealing, damping( shocking proof), silencers and exhaust gas purification components of auto parts. Electronics and electrical products EMI shielding devices



compressed knitted mesh

compressed knitted mesh
compressed knitted mesh compressed knitted mesh

Features & Benefits:

  • Interlocking wire loop structure.
  • Withstand high temperature & corrosions.
  • Withstand thermal shock and vibration without breaking up.
  • Excellent filtration capability.
  • Available in any special forms.
  • Ideal for depth filtration.
  • Economical cost.

Applications:

  • Airbag slag filters.
  • Kitchen range hood grease filter.
  • Intake filters for air compressors.
  • Air intake filters for automotive vehicles & engines.
  • Fuel filters.
  • Fuel injection filters.
  • Oil & air breather elements.
  • Oil bath separators.
  • Engine breathers.
  • Attenuation filters in pneumatic tools.
