10x10 10 Gauge Welded Wire Mesh Hot Dipped Galvanized For Protection

10x10 10 Gauge Welded Wire Mesh Hot Dipped Galvanized For Protection
10x10 10 Gauge Welded Wire Mesh Hot Dipped Galvanized For Protection 10x10 10 Gauge Welded Wire Mesh Hot Dipped Galvanized For Protection 10x10 10 Gauge Welded Wire Mesh Hot Dipped Galvanized For Protection 10x10 10 Gauge Welded Wire Mesh Hot Dipped Galvanized For Protection

Large Image :  10x10 10 Gauge Welded Wire Mesh Hot Dipped Galvanized For Protection

Product Details:
Place of Origin: HeBei,China
Brand Name: QiJie
Certification: Certification ISO2019046
Model Number: SGS2019046
Payment & Shipping Terms:
Minimum Order Quantity: 50 rolls
Price: Discuss
Packaging Details: 1.Welded wire mesh in panel: Are wrapped with the shrink plastic bag when packed in the pallets. / in bulk 2.Welded wire mesh in rolI: Are by waterproof paper then shrink plastic bag as ou negotiation. 3.Special packing is ok as your request for Weld
Delivery Time: About 15-30 days
Payment Terms: 30%TT
Supply Ability: 2000 Ton/Tons per Month
Detailed Product Description
Material:: Galvanized /Low-Carbon/Stainless Steel Iron Wire Application:: Cage /fence Mesh/gabions And So On
Hole Shape:: Square Wire Gauge:: 2.0-4.0mm
Color:: Silver Usage:: Protection
Length:: 5m,10m,25m,30metc Width:: 0.5-1.8m
High Light:

welded wire fabric

,

welded wire sheets



Cheap price 10x10 10 gauge hot dipped galvanized welded wire mesh



Product Description

This kind of welded wire mesh is made with plain steel wire welded together in the square opening, then going through the hot dipped zinc coating process.
Hot dipped zinc coated welded wire mesh is made in accordance to English Standard normally in regard to the production and zinc coating. The finished welded mesh offer flat and uniform surface, firm structure, good integrity. It offers the most excellent anti-corrosion resistance among all the steel wire mesh products, it is also the most versatile wire mesh due to its wide application in different fields.
Features and Application:
It is very popular in breeding industry: Can be made into various animal cages or fences for breeding with its excellent anti-corrosion property. The zinc coating offers a kind of decorative outlook with its flat surface.
With first-class anti-corrosion property, it is widely used in mine sieving industries as sieving screen. The low carbon steel wire for the making of hot-dipped welded wire mesh offers flexibility that can be made in many further fabrication applications.
We supply hot dipped galvanized welded wire mesh in the following forms: In rolls; In panels.

10x10 10 Gauge Welded Wire Mesh Hot Dipped Galvanized For Protection 0

Specificat List Of Welded Wire Mesh
Opening Wire Diameter
In inch In metric unit(mm)
1/4x1/4 6.4mmx6.4mm 22,23,24
3/8x3/8 10.6mmx10.6mm 19,20,21,22
1/2x1/2 12.7mmx12.7mm 16,17,18,19,20,21,22,23
5/8x5/8 16mmx16mm 18,19,20,21
3/4x3/4 19.1mmx19.1mm 16,17,18,19,20,21
1x1/2 25.4mmx12.7mm 16,17,18,19,20,21
1-1/2x1-1/2 38mmx38mm 14,15,16,17,18,19
1x2 25.4mmx50.8mm 14,15,16
2x2 50.8mmx50.8mm 12,13,14,15,16
TIP: Special specification can be customized!
PVC Coated Welded Mesh
Opening Wire Diameter
In inch In metric unit(mm)
1/2x1/2 12.7mmx12.7mm 16,17,18,19,20,21
3/4x3/4 19mmx19mm 16,17,18,19,20,21
1x1 25.4mmx25.4mm 15,16,17,18,19,20



Specification
Wire diameter (mm) Hole size
Path distance (mm) Weft spacing (mm) Length (m) Width (m)
10 100--500 30--300 1--8 0.5--3
9 100--500 30--300 1--8 0.5--3
8 100--500 30--300 1--8 0.5--3
7 50--200 20—300 1--8 0.5--3
6 50--200 20—200 1--8 0.5--3
5 50--200 10—200 1--8 0.5--3
4 30--200 10—200 1—8 0.5--3
2--4 25--100 10--100 1--6 0.5--3
Galvanized Welded Mesh Fencing
Opening Wire Diameter
In inch In metric unit(mm)
2" x 3" 50mm x 75mm 2.0mm,2.5mm,1.65mm
3" x 3" 75mm x 75mm 2.67mm,2.41mm,2.11mm,1.83mm,1.65mm
2" x 4" 50mm x 100mm 2.11mm,2.5mm
4" x 4" 100mm x 100mm 2.0mm,2.5mm

Panel:The panels with diameters ranging from 3.0 mm to 6.0 mm, which ensure a very high stiffness of the fence. The panels up to 2000mm, 2500 mm,3000mm wide and with heights ranging from 630 mm to 2500 mm.

Stainless steel welded wire mesh panel
Mesh Wire diameter Width(feet)
2"×3" BWG8,10,12 2-8.2
2"×4" BWG6,8,11,12 2-8.2
3"×3" BWG6,8,10,11 2-8.2
4"×4" BWG3,4,5,6,8,9,10 2-8.2
4"×6" BWG3,4,5,6,8,9,10 2-8.2
6"×6" BWG0,2,4,6,7,8,9 2-8.2

Welded Wire Mesh Panel is made of superior quality steel wire or iron wire rod, with flat surface, firm structure. After PVC powder coating or galvanization, the welded wire mesh panels can resist the corrosive. It's used extensively in building, agriculture and so on.
1. Material of Welded Wire Mesh Panel
Low carbon steel wire, galvanized iron wire, stainless steel wire.
2. Assortments of Welded Wire Mesh Panel
Galvanized Welded Mesh Panels
Stainless Steel Wire Mesh Panels
Hot-dip Zinc Plating Welded Mesh Panels
PVC coated Welded Mesh Panels
3. Application of Welded Wire Mesh Panel
Widely used in construction reinforcement, the ground for the tunnels, bridges, highway, airport and wharf, construction of wall body, also in decorative architecture.
4. Advantages of Welded Wire Mesh Panel
Welding firm, mesh hole even, the mesh surface smooth, corrosion resistance, strength, strong protective capability.
5. Processing of Welded Wire Mesh Panel
Welding with iron wire or wire rod (without surface treatment)
Hot dipped galvanizing before welding
Hot dipped galvanizing after welding
Electric galvanizing before welding
Electric galvanizing after welding
PVC powder coating after welding

Application

For industry, agriculture, construction, transport,transprotation, mining, mine playground,Stadium, lawn, aquaculture,cultivation, enclosurefence, decoration,ect.

Suitable product for constructing animal cages, enclosure works, fabricating of wire containers and baskets, grills, partitions, machine protection fences, gratings and other construction applications.

Packaging & Shipping

Packing Details :

1. welded wire mesh in panel: are wraped with the shrinked plastic bag then packed in the pallets.
2. welded wire mesh in rolI:are by water proof paper then shrinked plastic bag as ou negotiation.
3. Special packing according to your requirement .


Delivery Details : 3-30 days after received the deposit.

10x10 10 Gauge Welded Wire Mesh Hot Dipped Galvanized For Protection 0
