Traction Aluminum Bar Galvanized Steel Grating Stair Treads , Perforated Grip Strut Treads

China Traction Aluminum Bar Galvanized Steel Grating Stair Treads , Perforated Grip Strut Treads supplier
Traction Aluminum Bar Galvanized Steel Grating Stair Treads , Perforated Grip Strut Treads supplier Traction Aluminum Bar Galvanized Steel Grating Stair Treads , Perforated Grip Strut Treads supplier

Large Image :  Traction Aluminum Bar Galvanized Steel Grating Stair Treads , Perforated Grip Strut Treads

Product Details:

Place of Origin: hebei,China
Brand Name: QIJIE
Certification: iso
Model Number: grip strut grating

Payment & Shipping Terms:

Minimum Order Quantity: 100pcs
Packaging Details: Pallets
Delivery Time: 15-18days
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability: 1000pcs per month
Contact Now
Detailed Product Description
Material: Aluminum,Galvanized Steel Wire Products Name: Grip Strut Grating
Type: Perforated Mesh,Etching Or Stamping Technique: Perforated
Weave Style: Perforated,Punched,Punching Hole Shape: Round,diamond,etc,plum Blossom,octagonal
Surface Treatment: Spray Coating/Spray Painting/Fluorocarbon Coating,Hot Dipped Galvanized,galvanized And Fluoroca Color: All The Color Chip Have,White,blue,Silver,golden
Product Name: Hexagonal Perforated Metal Sheet,expandable Sdiamond Mesh Thickness: 0.5-8mm,0.3MM- 8MM
Feature: Corrosion Resistance,Good-looking And Good Quality,Durable,Acid Resistance,anti-resistance Width: 1m Or 1.22m,1.22 M Or Below
Usage: Etc.,decorative,oil/air Filter,food Length: 2m Or 2.44m
Size: Customized Size,standard Shape: Square,Can Be Cut Into Round Or Square Shape,Round Shape,oval,Hexagon
Pitch: 1.0mm-100MM,or As Request.

Traction Tread Stair Treads, Perforated Grip Strut Treads, Aluminum Grating Stair



Grtp Strut Grating Plates are one-piece modules manufactured with integral side toe boards projecting above the walking surface of the flooring.

Ideal for elevated applications such as suspended walkways or conveyor catwalks, these channels provide safe, economical,

slip resistant options for long span walkways. Continuous spans can be accommodated by welding adjacent planks or

specifying splice plates as illustrated below.



Material:Hot rolled,Cold rolled, Aluminum,Stainless Steel,etc
Hole patterns: Crocodile Mouth,Round raised hole,and tears shape,alligator mouth,etc.
Thickness:1.5mm-5mm
Length: Max 4m
Types: PERF-O GRIP Grating, HEAVY DUTY GRIP STRUT, TRACTION TREAD FLOORING
Application:works great as the safety grating of sewage treatment plant,power
plant,and work plant,etc,as well as the platform scaffoldings and stair treads for snowy

grip strut grating

2 Diamond / 9-1/4" Width
Diamond Pattern Width Channel Depth galvanized Aluminum
2 Diamonds 9-1/4" 2" 11 Ga., 10 Ga., 9Ga. 12 Ga. (.080"), 10 Ga. (.100")
9-1/4" 2-1/2" 11 Ga., 10 Ga., 9Ga. 12 Ga. (.080"), 10 Ga. (.100")
9-1/4" 3" 11 Ga., 10 Ga., 9Ga. 12 Ga. (.080"), 10 Ga. (.100")
9-1/4" 4" 11 Ga., 10 Ga., 9Ga. 12 Ga. (.080"), 10 Ga. (.100")
3 Diamond / 13-3/4" Width
Diamond Pattern Width Channel Depth galvanized Aluminum
3 Diamonds 13-3/4" 2" 11 Ga., 10 Ga., 9Ga. 12 Ga. (.080"), 10 Ga. (.100")
13-3/4" 2-1/2" 11 Ga., 10 Ga., 9Ga. 12 Ga. (.080"), 10 Ga. (.100")
13-3/4" 3" 11 Ga., 10 Ga., 9Ga. 12 Ga. (.080"), 10 Ga. (.100")
13-3/4" 4" 11 Ga., 10 Ga., 9Ga. 12 Ga. (.080"), 10 Ga. (.100")
5 Diamond / 23-1/4" Width
Diamond Pattern Width Channel Depth galvanized Aluminum
5 Diamonds 23-1/4" 2" 11 Ga., 10 Ga., 9Ga. 12 Ga. (.080"), 10 Ga. (.100")
23-1/4" 2-1/2" 11 Ga., 10 Ga., 9Ga. 12 Ga. (.080"), 10 Ga. (.100")
23-1/4" 3" 11 Ga., 10 Ga., 9Ga. 12 Ga. (.080"), 10 Ga. (.100")
23-1/4" 4" 11 Ga., 10 Ga., 9Ga. 12 Ga. (.080"), 10 Ga. (.100")
6 Diamond / 27-3/4" Width
Diamond Pattern Width Channel Depth galvanized Aluminum
6 Diamonds 27-3/4" 2" 11 Ga., 10 Ga., 9Ga. 12 Ga. (.080"), 10 Ga. (.100")
27-3/4" 2-1/2" 11 Ga., 10 Ga., 9Ga. 12 Ga. (.080"), 10 Ga. (.100")
27-3/4" 3" 11 Ga., 10 Ga., 9Ga. 12 Ga. (.080"), 10 Ga. (.100")
27-3/4" 4" 11 Ga., 10 Ga., 9Ga. 12 Ga. (.080"), 10 Ga. (.100")
8 Diamond / 36" Width
Diamond Pattern Width Channel Depth galvanized Aluminum
8 Diamonds 36" 1-1/2" 11 Ga., 10 Ga., 9Ga. 12 Ga. (.080"), 10 Ga. (.100")
36" 2" 11 Ga., 10 Ga., 9Ga. 12 Ga. (.080"), 10 Ga. (.100")
36" 2-1/2" 11 Ga., 10 Ga., 9Ga. 12 Ga. (.080"), 10 Ga. (.100")
36" 3" 11 Ga., 10 Ga., 9Ga. 12 Ga. (.080"), 10 Ga. (.100")





pattern of grip strut grating

drawing of grip strut grating



Applications of Grip Strut Plank
Grip Strut Plank can be made out of iron plate, aluminium plate or stainless steel plate, etc, based upon different working environments. If iron plate is used, when grip strut plank is ready, it can be electro-galvanized, hot dip galvanized or spray-painted. Grip strut plank has nicer skid resistance and beautiful look, so it is widely used as stair tread, walkway and workshop floor in factories and transportation facilities, etc. When grip strut plank is covered with mud, ice, snow, grease, oily soil or cleaning media, grip strut plank can efficiently safeguard the safety of operating personnel.





Characteristics of the perforated Grtp Strut Grating:



With non-slip, anti-rust, anti-corrosion, durable features and beautiful appearance. Punching hole type with raised herring

bone, raised crosswise, round, crocodilelips type, tear-type. These hole types are all CNC punching holes.



Advantages of Grip Strut Safety Grating:

  • Open diamond pattern allows for the drainage of fluids, mud, chips, and other accident-causing debris through floor grating and stair treads

  • Range of widths from 4-3/4" to 36"

  • Grip Strut safety metal grating walkways meet OSHA requirements for toe boards on elevated structure

  • Grip Strut is available in Regular, Heavy Duty, Walkway, and Stair Treads

  • Available in galvanized steel, carbon steel, stainless steel, and aluminum



grip strut grating



grip strut grating grip strut grating
grip strut grating grip strut grating
grip strut grating grip strut grating
