Fast Fully - Automatic Wire Mesh Machine , Electric Chain Link Machine

China Fast Fully - Automatic Wire Mesh Machine , Electric Chain Link Machine supplier
Fast Fully - Automatic Wire Mesh Machine , Electric Chain Link Machine supplier Fast Fully - Automatic Wire Mesh Machine , Electric Chain Link Machine supplier

Large Image :  Fast Fully - Automatic Wire Mesh Machine , Electric Chain Link Machine

Product Details:

Place of Origin: HeBei,China
Brand Name: QiJie
Certification: Certification
Model Number: SGS008

Payment & Shipping Terms:

Minimum Order Quantity: 1 set
Price: 4999-6999$
Packaging Details: pack in plastic film
Delivery Time: within 7-30 days
Supply Ability: 10 sets per week
Contact Now
Detailed Product Description
Product Name: Fast Fully - Automatic Wire Mesh Machine , Electric Chain Link Machine Type: Fully Automatic
Application: Hexagonal Wire Mesh Making Mesh Width: 2500mm
Mesh Type: Roll Form, Rolling Mesh, Panel Mesh Mesh Size: Can Be Customizable, 1/4"-6", 3/4", 1", 1/2"
Voltage: 220V/380V/415V/440V, 380V Color: Blue / Can Be Customized

                        fully-automatic chain link fence machine with Factory direct sales cheap price

Technical parameter

Automatic chain link fence machine line includes: main machine,weaving machine,mesh cutting machine,compacting bundling machine or normal rolling machine,border wire treating machine(knuckling and twisting) ,PLC control cabinet, Wire inlet frame,2 sets of molds ,pay-off rack,Soap pot .
Woven wire diameter
1.8-4.5mm
Mesh opening:
30mm--120mm
Width
600-6000mm
Motor Power:
5.5kw+2.2kw+1.5kw+1.5KW
Production capacity:
80-200m2/h
Mesh side
Knuckled and twisted, both knuckled, both twisted
Raw material
Galvanized wire,PVC coated wire,etc.
Size
4.5mx2.3mx1.5m for 3m width of chain link fence machine
Weight
2500kgs for 3m width of chain link fence machine
Mould
2sets for free



Fast Fully - Automatic Wire Mesh Machine , Electric Chain Link Machine

Full Automatic Chain Link Fence Machine is a new automatic type machine for Chain Link Mesh. It is develops on the basis of semiautomatic mechanical and the mechanical and electrical completely automatic machine, It is a comprehensive model machine, that gather the machinery and pneumatic. And its structure is very simple, the weight is light, and take less place. And it adopt the new Frequency and electronically controlled clutch, can operated convenient and maintenance simply. The general knowledge is very easy to hold, onespecialized worker can operated several sets machine,the output is high, it is the best choice for the Business, factories,and individual.

Chain link accessories

1. Flat iron : support chain link fence
2. Brace band :link tensioner & post
3. Tension band : Link the flat iron & post
4. Tensioner : secure the line wire
5. Line wire : Folding the chain link mesh
6. Tie wire & Stirrup wire :secure the line wire & post and secure the post and the mesh

Electric Chain Link Machine

Packing & Delivery

Electric Chain Link Machine

Main Features

1) Simple structure in linear type ,easy in installation and maintation.

2) Adopting advanced world famous brand components in pneumatic parts ,electric parts and operation parts.

3) High pressure double crank to control the die opening and closing.

4) Running in a high automatization and intellectualization,no pollution

5) Apply a linker to connect with the air conveyor ,which can directly inline with filling machine .

FAQ

1. Do you provide samples?
We can provide most of free samples to you if it is 4"X4" maximum.

If you want more or larger piece of sample, we will quote for u for your reference.

Cut-to-size and special design is available after we negotiated well.

2. What is your payment term?
Generally, our payment term is T/T 30% in advance and the balance 70% against the copy of B/L.

LC at sight is acceptable.

Other payment term we can discuss.



3. What is your standard of wire and wire mesh?
