Powder Coated Welded Wire Mesh Fence Panels For Prison With Square Hole

China Powder Coated Welded Wire Mesh Fence Panels For Prison With Square Hole supplier
Powder Coated Welded Wire Mesh Fence Panels For Prison With Square Hole supplier Powder Coated Welded Wire Mesh Fence Panels For Prison With Square Hole supplier Powder Coated Welded Wire Mesh Fence Panels For Prison With Square Hole supplier Powder Coated Welded Wire Mesh Fence Panels For Prison With Square Hole supplier

Large Image :  Powder Coated Welded Wire Mesh Fence Panels For Prison With Square Hole

Product Details:

Place of Origin: China
Brand Name: Qijie
Certification: ISO9001
Model Number: QJ-A001

Payment & Shipping Terms:

Minimum Order Quantity: 100 sets
Price: $15.5-46.5/ set
Packaging Details: in pallet
Delivery Time: 15-20 days
Payment Terms: T/T, Western Union, MoneyGram, L/C
Supply Ability: 600 sets per week
Contact Now
Detailed Product Description
Material: Galvanized Steel Wire Weave Style: Welded
Wire Diameter: 3-6mm Openning: 12.7 X 76.2 Mm
Feature: Corrosion Resistance,beautiful,durable Surface Treatment: Powder Coated,PVC Coated,Hot Dipped Galvanized
Usage: Construction,security Hole Shape: Square Hole



Powder Coated High Security 358 Anti-Climb Welded Wire Mesh Fence For Prison



    Why is it called 358 Security Fence? '358' comes from its measurements 3" × 0.5" × 8 gauges which equates to approx. 76.2mm × 12.7mm × 4mm (Length × height × Diameter) in metric.358 security fences are extremely difficult to penetrate, with the small mesh aperture being effectively finger proof, and extremely difficult to attack using conventional hand tools. 358 fences are recognized as one of the most difficult to break through the barrier, because it is difficult to climb. It is called security fencing and high- strength fencing. 358 security fencing panel can be bent in part to enhance the aesthetic effect.
    While 3510 Security Fencing has many of the attributes of 358 Security Fencing and its main strength is it's lighter. Using 3mm wire instead of 4mm allows even better visibility allowing a wider variety of applications. It`s lighter and cheaper so it's ideal for commercial applications.



Advantage:

Anti-climb: More small openings, no toe or finger holds.

Anti-cut: robust wire and welded joints make cutting very difficult.

High-strength: The superior welding technique and process control create a stronger fusion between the wires.

Finish treatment: there are two treatment types: hot dipped galvanized and plastic coated.

The colors of plastic coated are mainly green and black. Each color is available according to your require.



Powder Coated Welded Wire Mesh Fence Panels For Prison With Square Hole



358 Security Wire Mesh Fence Specifications

Master View 358 2.1m 2.4m 3.0m
Panel height 2134mm 2438mm 2997mm
Panel width 2515mm 2515mm 2515mm
Mesh size 12.7 x 76.2mm 12.7 x 76.2mm 12.7 x 76.2mm
Horizontal wire 4mm 4mm 4mm
Vertical wire 4mm 4mm 4mm
Panel weight 50kg 57kg 70kg
Posts 60 x 90 x 4 mm 60 x 90 x 4 mm 80 x 80 x 4 mm
Post length 2.8m 3.1m 4.0m


358 Security Fence Finish

Forms of corrosion resistance include electric galvanizing, hot-dipp galvanizing, PVC spraying and PVC coating.

Colours: Standard colours are Green RAL6005, Black RAL9005 and Yellow RAL1021. Other colours are available on request.



Options:
A variety of anti-climb structures may be installed to the mesh top such as:

Razor mesh

100mm high galvanized Shark tooth spike rails

100mm high galvanized castle spikes

Lines of electric fence wires

Powder Coated Welded Wire Mesh Fence Panels For Prison With Square Hole



358 anti-climb wire mesh fence package:

Powder Coated Welded Wire Mesh Fence Panels For Prison With Square Hole



Powder Coated Welded Wire Mesh Fence Panels For Prison With Square Hole



FAQ

FREQUENTLY ASK QUESTIONS:(If your questions are unlisted on below, pls let us know.)

-Q-: What makes your fence products different from other company’s?
-A-: We provide free design service, customization and warranty service, with strictly quality control and very competitive price.



-Q-: Can I get a pcs of your products sample?
A-: Yes, samples will be provided anytime.



-Q-: What type of materials do you use for fence?
A-: Most of the wire we use is low carbon steel wire. The core wire for razor wire is high tension strength steel wire. Post material is Q235.



-Q-: Will my fence rust, peel, fade or chip?
A-: It shows more details in our warranty policy. If without man-made crash, punch, acid wash, etc, the surface can last for more than 10 years.



-Q-: What are fittings and how are they used?
-A-: We have hundreds of fittings for our fence products. Different type of fence comes with different accessories



-Q-: How do I take care of my new fence?
-A-: Just try to avoid man-made crash, acid, etc.



-Q-: What type of fencing do you offer?
-A-: Our mail products are welded mesh fence, double wire fence, 358 high security fence, chain link fence, temporary fence, portable fence, airport fence, barbed wire, concertina razor wire, razor wire fence and gabion box, etc.
