Product Details:
Payment & Shipping Terms:
|
| Size: | 0.914m X 30m | Material: | UNS S31000 - 310 |
|---|---|---|---|
| Weave: | Dutch Woven | Mesh: | 40mesh |
| Technique: | Woven | Application: | Woven Wire Mesh,Filters,Screen,Decorative Wire Mesh,Protecting Mesh |
| Type: | Weave Wire Mesh,Wire Cloth,Crimped Wire Mesh,Rope Mesh | Weave Style: | Plain Weave,twill Weave,Plain/Twill Weave,plain/twill/dutch Weave,Dutch Weave |
| High Light: | 0.914x30m stainless steel screen mesh,sus304 screen mesh,SGS Stainless Steel Screen Mesh |
||
304 Stainless Steel Screen Mesh, PVC Coated Black/ Powder Coated Black
powder coated or epoxy coated 304 and 316 stainless steel meshes for insect screening products. This type of s.s. mesh screen is mostly in the treatment of PVC coating or black powder coating finish. Also known as black powder coated Stainless Steel Mesh Insect Screen. With firm and flat coated surface, the wire mesh screen offers good ventilation and excellent strength, suitable for keeping flies and mosquitoes out of windows and doors.
The powder coated stainless screen can be divided into two types according to basic mesh materials: Powder coated 304 mesh screen and Black Powder Coated 316 series insect screen. We also supply non-powder coating stainless steel window screen with natural finishes.
304 Stainless steel Screen Mesh, PVC coated black/ Powder Coated Black
Specifications
Mesh Size/ Count Mesh - Wire Diameter
18 x 16 - 0.26 mm
20 x 20 - 0.25 mm
16 x 16 - 0.24 mm
Open Area – Around 70%.
Roll Size/Width - 3',4', 5’.
Black Powder Coated 316 and 316L Security Mesh for Window Screen
Materia: 304,316,316L ,T316 etc stainless steel wire
Surface treatment: Epoxy or PVC powder coating. Color can be black ,white ,grey
Weave type: Plain weave
Wire diameter: 0.6mm,0.7mm,0.8mm,0.9mm
Mesh size: 10-14 mesh
Common size: 0.6mm-14 mesh , 0.7mm-12 mesh, 0.8mm-11 mesh , 0.9mm-10 mesh
Wire mesh roll size: 750x2000mm, 900x2000mm,1200x2000mm,750x2400mm, 900x2400mm,1200x2400mm
Applications: Widely used on doors and windows for protect also prevent insects and flies.
Hehua also supplies stainless steel natural finish wire mesh for window screening uses, without any powder coating.
304 Stainless Steel Mesh Window Screen Natural Finish with No Powder Coating
Specifications
Mesh Size/ Count Mesh - Wire Diameter
18 x 16 - 0.27mm
14 x 14 -0.35 mm
Benefits and Features:
