Durable Architectural Woven Wire Drapery for Building Facade & Cladding
Decorative metal mesh is a product embraced by curtain wall designers, interior designers, and craftspeople. From decorative accents and
cabinets to lighting features and privacy screens, design possibilities are endless.
Each distinct pattern of Hightop decorative metal mesh is itself a work of art, designed with a specific geometry, open area, dimension,
and flexibility. Woven by skilled artisans from a multitude of combinations of highly durable, yet readily recyclable metals, including stainless,
bronze, aluminium, and brass, metal fabric is and intrinsically sustainable building material.
Specifications:
Material: Flat stainless steel wire,including ss304 ss316
Flat Wire Diameter: 1.0mmx4mm
Opening Size: 5.0mm
Thickness: 2mm
Open Area: 31%
Weight: 7.1kg/m2
Max width: 1500mm
Max length: 3000mm
Surface treatment: Antique brass surface finished, Spraying plated surface finished, PVD color surface finished, anodizing.
Color: antitque brass/copper, rose gold, gold
pecifications of Einstein Series Decorative Antique Brass Mesh Screen
| Product Name |
Einstein-307AB |
Einstein-310AB |
Einstein-405AB |
Einstein-304AB |
Einstein-305AB |
Einstein-2503AB |
| Material |
SS 304/316 |
SS 304/316 |
SS 304/316 |
SS 304/316 |
SS 304/316 |
SS 304/316 |
| Wire Size (a), mm (in) |
3 (.118) |
3 (.118) |
4 (.157) |
3 (.118) |
3 (.118) |
2.5 (.098) |
| Opening (b), mm (in) |
7 (.276) |
10 (.394) |
5 (.197) |
4 (.157) |
5 (.197) |
3 (0.118) |
Overall thickness,
mm (in) |
2.5 (.098) |
3 (.118) |
2 (.079) |
2.5 (.098) |
2 (.079) |
2 (.079) |
| Open Area |
50% |
60% |
33% |
31% |
40% |
30% |
| Max Width |
1.2m (4 ft) |
1.2m (4 ft) |
1.2m (4 ft) |
1.2m (4 ft) |
1.2m (4 ft) |
1.2m (4 ft) |
| Max Length |
2.8m (9 ft) |
2.8m (9 ft) |
2.8m (9 ft) |
2.8m (9 ft) |
2.8m (9 ft) |
2.8m (9 ft) |
Approx. Weight,
kg/m2 (lb/ft2) |
5.8 (1.19) |
5.6 (1.15) |
7.1 (1.45) |
8.3 (1.70) |
6.3 (1.29) |
7.4 (1.52) |
Feature:
Various color for your option, and the color won’t fade.
Superb technology and smooth surface of the product.
Nice regular Crimp create fantastic appearance.
Metal material has high strength, it is sturdy, durable, anti-flame and corrosion-resistant.
Easy to clean and maintain.
Application:
Cabinetry Mesh, Door Mesh, Divider Mesh, Partition Screen Mesh, Stair Mesh, Interior Home Decor Mesh.
