Black Galvanized Iron Wire Automatic Welded Mesh Machine With PLC Touch Screen

China Black Galvanized Iron Wire Automatic Welded Mesh Machine With PLC Touch Screen supplier
Black Galvanized Iron Wire Automatic Welded Mesh Machine With PLC Touch Screen supplier Black Galvanized Iron Wire Automatic Welded Mesh Machine With PLC Touch Screen supplier Black Galvanized Iron Wire Automatic Welded Mesh Machine With PLC Touch Screen supplier Black Galvanized Iron Wire Automatic Welded Mesh Machine With PLC Touch Screen supplier Black Galvanized Iron Wire Automatic Welded Mesh Machine With PLC Touch Screen supplier

Large Image :  Black Galvanized Iron Wire Automatic Welded Mesh Machine With PLC Touch Screen

Product Details:

Place of Origin: Heibei, China
Brand Name: Qijie
Certification: ISO CE SGS
Model Number: QJ-010

Payment & Shipping Terms:

Minimum Order Quantity: 1 Set
Price: USD 12000 -- 25000
Packaging Details: plastic film
Delivery Time: 20-25 days
Payment Terms: TT
Supply Ability: 6 set/month
Contact Now
Detailed Product Description
Hole Shape: Square, Rectangle Width: 1-3m
Hole Size: 2.5cm-150cm Material: Black Or Galvanized Wire
Operation: Fully Automatic Control System: PLC Touch Screen
Voltage: 220V/380V/415V/440V Welding Head Material: High Chromium Copper

Galvanized Iron Wire and Black Wire Automatic Welded Mesh Machine





Wire mesh welding machine is professionally used to produce construction mesh, controlled by the special computer, the welding current and welding time in each welding transformer can be individually adjusted. The machine operating interface is made up with color touch screen and control buttons, easy to operate.





Type
Semi-automatic Fence Panel Welded Machine
Automatic Fence Panel Welded Machine
Wire diameter
5-12mm
5-12mm
Wire space
100-300mm
100-300mm
Mesh width
1100mm-2500mm
2500mm
Welding spot
24
24
Mesh length
3m-12m
0.5m-16m
Welding speed
50-60 times/min
50-60 times/min
Voltage power
380V/50Hz(3 phase)/customized
380V/50Hz(3 phase)/customized
Transformer capacity
150KVA*12(water cooling)
150KVA*12
Weight approx
14ton
25.0ton
Overall dimension approx
26×5.0×2.3m
42000×5500×3300mm
Motor
11.0kw(invert-er braking)
11kw
Outside transformer power
250-315KVA(within 100 meters)
315-500KVA(within 150 meters)
Way of pressure
Mechanical
Mechanical
Line wire feeding way
Pre-straightening and cutting
Fully automatic by coils
Cross wire feeding way
Pre-straightening and cutting
Pre-straightening and cutting







Applications


Application materials : welding machine is good at welding various metal wire : stainless steel wire , low carbon steel wire , round steel bar, ribbed steel bar

Application mesh panel : welded mesh panel widely used as reinforce mesh panel for building, construction ;railway wire mesh fence, security fence and others.





Standard accessory



1,Straightening Automatically and Cutting Machine : two/set

2,Wire Tray :two piceses



 Automatic Welded Mesh Machine



Fence Mesh Welding Machine Function features and advantages:
1. This machine adopts electrical & electronic synchronous control technique, both separate-phases welding and welding time composed of digital and integrated electric circuit. The input panel has two types touch screen and button, more intelligent and rational, once pressing, and separate welding.
2. The welding power is electric power. The cross wire is fed from hopper driven by stepper motor, and the line wire is fed by brake motor driven car and the mesh is pulled by the stepper motor driven car.
3. The cross and the line wires are both pre-straightened and pre-cut by the special straightening and cutting machine.
4. The biggest advantage of the machine is that there is different cross spacing in the same mesh.
5.The welding electrodes and transformer are equipped with the water cooling system,thus prolong the machine life and working time.
