Product Details:
Payment & Shipping Terms:
|
| Material: | Low Carbon Steel Wire, Galvanized Wire,stainless Steel Wire, Aluminum-magnesium Alloy Wire | Process: | Welded After Galvanized And Galvanized After Welding |
|---|---|---|---|
| Mesh: | 75mm×150mm | Size: | 1800mm×3000mm(or More) |
| PVCCoating Thickness: | 0.5mm~1.0mm | Packing: | Bare Or Pallet |
| Color: | Silver | ||
| High Light: | 2.4mx5.8m welded mesh galvanised wire panel,silver welded mesh galvanised wire panel,welded wire mesh panel 2.4mx5.8m |
||
| Specification List of Welded Wire Mesh | ||
| Opening | Wire Diameter | |
| In inch | In metric unit(mm) | |
| 1/4" x 1/4" | 6.4mm x 6.4mm | 22,23,24 |
| 3/8" x 3/8" | 10.6mm x 10.6mm | 19,20,21,22 |
| 1/2" x 1/2" | 12.7mm x 12.7mm | 16,17,18,19,20,21,22,23 |
| 5/8" x 5/8" | 16mm x 16mm | 18,19,20,21, |
| 3/4" x 3/4" | 19.1mm x 19.1mm | 16,17,18,19,20,21 |
| 1" x 1/2" | 25.4mm x 12.7mm | 16,17,18,19,20,21 |
| 1-1/2" x 1-1/2" | 38mm x 38mm | 14,15,16,17,18,19 |
| 1" x 2" | 25.4mm x 50.8mm | 14,15,16 |
| 2" x 2" | 50.8mm x 50.8mm | 12,13,14,15,16 |
| Technical Note: 1,Standard roll length: 30m;width: 0.5m to 1.8m 2,Special sizes available at request 3,Packing: in waterproof paper in rolls. Custom packing available at request. |
||
Contact Person: Mr. Devin Wang
Fax: 86-318-7896133
