Hot Dipped 10 Gauge Galvanized Welded Mesh Panel 2x2 Inch Opening Mining Use

Name: Hot Dipped 10 Gauge Galvanized Welded Mesh Panel 2x2 Inch Opening Mining Use
Brand: qijie
SKU: welded mesh panel
Price: 1 USD
Availability: InStock
Rating: 4.5 (118 reviews)

Large Image : Hot Dipped 10 Gauge Galvanized Welded Mesh Panel 2x2 Inch Opening Mining Use

Product Details:

Place of Origin:	China
Brand Name:	qijie
Certification:	SGS
Model Number:	welded mesh panel

Payment & Shipping Terms:

Minimum Order Quantity:	200pcs
Packaging Details:	pallets
Delivery Time:	15-20days
Payment Terms:	30%TT in advance, Balance before loading
Supply Ability:	1000pieces

Contact Now

Detailed Product Description

Color:	Green, Silver, Etc	Panel Length:	1.0-5.0m
Wire Diameter:	2-6mm	Mesh:	75mm×150mm
Panel Width:	0.5-1.8m	SpecificationThickness:	0.9*1.8m
Packing:	Bare Or Pallet
High Light:	10 gauge galvanized welded mesh panel , 2x2 inch galvanized welded mesh panel , 2x2 galvanized welded wire mesh panel

Product Description

1. Product Description:
The welded wire mesh is welded by excellent low carbon iron wires and
Passivated and plasticized through cold plating (electroplating), hot dipping
And PVC plastic coating. With flat surface, even mesh count, firm welding
Spots and stable structure, it features its strong completeness, partial good
Machining performance, stability, excellent corrosion resistance and rush
Prevention.

2. Materail:
Low Carbon Iron Wire

3. Treatment:
1>Hot dipped galvanized and welding
2>Elcetro galvanized and welding
3>PVC coated galvanized and welding

4. Product Processing:
1>Iron wire→Welding→Hot dipped galvanized
2>Iron wire→Electro galvanized→Welding
3>Iron wire→Electro galvanized→Welding→PVC Coated

5. Fence Specifications:

Opening (inch)	Opening (mm)	Wire Diameter	Wire Diameter	Panel Length	Panel Width
1"x1"	25mmx25mm	14#-11#	2.0mm-3mm	1.0-5.0m	0.5-1.8m
2"x1"	50mmx25mm	14#-8#	2.0mm-4mm
2"x2"	50mmx50mm	14#-8#	2.0mm-4mm
3"x2"	75mmx50mm	14#-6#	2.0mm-5mm
3"x3"	75mmx75mm	14#-6#	2.0mm-5mm
4"x2"	100mmx50mm	14#-4#	2.0mm-6mm
4"x4"	100mmx100mm	14#-4#	2.0mm-6mm
5"x5"	125mmx125mm	14#-4#	2.0mm-6mm
6"x6"	150mmx150mm	14#-4#	2.0mm-6mm
