Light Duty Aluminum Expanded Metal Mesh Decorative For Exterior Wall Cladding

Light Duty Aluminum Expanded Metal Mesh Decorative For Exterior Wall Cladding
Light Duty Aluminum Expanded Metal Mesh Decorative For Exterior Wall Cladding

Large Image :  Light Duty Aluminum Expanded Metal Mesh Decorative For Exterior Wall Cladding

Product Details:
Place of Origin: China
Brand Name: QIJIE
Certification: CE,SGS,ISO
Model Number: QJ-E006
Payment & Shipping Terms:
Minimum Order Quantity: 500 square meters
Price: USD 1-10/M3
Packaging Details: pallets
Delivery Time: 5-10 working days
Payment Terms: 30%TT in advance, Balance before loading
Supply Ability: 800m3/day
Detailed Product Description
Material: Aluminum Sheet,Stainless Steel/Aluminum,galvanized Plate Application: Protecting Mesh,Filters,Screen,Fencing
Type: Expanded Mesh,Flattened And Standard Weave Style: EXPANDED METAL
Color: Silver,red,Black,white,yellow
High Light:

expanded metal lath

,

expanded mesh panels

Light Duty Aluminum Expanded Metal Mesh Decorative For Exterior Wall Cladding

Aluminum expanded metals,have a very good strength and corrosion resistance the most versatile and economical expanded metal mesh product for construction,decoration,ventilation,security guards, industrial,etc. Aluminum expanded metal is made from the sheets or coils of aluminum or aluminum alloy,which are uniformly slit and stretched, forming a diamond pattern of openings in the finished sheet. They have various of patterns by the adjustment of thickness,strand and the size of the diamond openings.

Description of Decorative Aluminum Expanded Metal Mesh



Expanded metal mesh is one of the most important fashionable decoration elements in civil buildings construction. This product is strong and beautiful, so it is suitable for using in many fields after processing. It is widely used in making of filters baskets, air filtration units, machine guards, metal cages, safety door & window screening, room dividers, decorative ceilings, highway fencing and civil

building.



Application of Decorative Expanded Metal Mesh



Displays,Tables,Chairs,Fireplace screens,Fencing,Endless security applications



  • Materials: Aluminum,Aluminum Alloy (1060,3003,5005,etc)
  • Surface treatment: Standard,Powder coating,Anodizing,PVDF coating

Decorative Expanded Metal Mesh

Specification:

  • Thickness : 0.3mm- 10.0mm
  • Strand : Regular or customized
  • SWD*LWD : 2*3,2*4,3*5,4*8,5*10,7*12,8*16,10*20,16*30,18*30,20*40,25*50,30*60,40*80,
    45*100,50*100,60*120mm,125*300mm etc.
  • LWM : Less than 3000 mm
  • SWM : customized

Specification of Decorative Expanded Metal Mesh



Sheet Thickness (mm) Opening in Width (mm) Opening in Length (mm) Stem (mm) Roll Width (mm) Roll Length (mm) Weight (kg/m2)
0.5 2.5 4.5 0.5 0.5 1 1.8
0.5 10 25 0.5 0.6 2 0.73
0.6 10 25 1 0.6 2 1
0.8 10 25 1 0.6 2 1.25
1 10 25 1.1 0.6 2 1.77
1 15 40 1.5 2 4 1.85
1.2 10 25 1.1 2 4 2.21
1.2 15 40 1.5 2 4 2.3
1.5 15 40 1.5 1.8 4 2.77
1.5 23 60 2.6 2 3.6 2.77
2 18 50 2.1 2 4 3.69
2 22 60 2.6 2 4 3.69
3 40 80 3.8 2 4 5.00
4 50 100 4 2 2 11.15
4.5 50 100 5 2 2.7 11.15
5 50 100 5 1.4 2.6 12.39
6 50 100 6 2 2.5 17.35
8 50 100 8 2 2.1 28.26



decorative of expanded metal mesh

Aluminum expanded metal mesh had a lighter weight than carbon steel expanded and stainless steel expanded and also available in a variety of surface, standard (raised) and flattened (smooth) surface according to the applications and projects requirements.

aluminum expanded metal mesh

Application:

Aluminum expanded metal has a widely applications in architectural,commercial,industrial and decoration.Such as suspended ceiling,curtain wall cladding,interior decoration, ventilation, filter,equipment guards, shelving, window protection,etc.

aluminum expanded metal mesh aluminum expanded metal mesh
aluminum expanded metal mesh Aluminum expanded metals
