Dutch Weave Stainless Steel 0.71mm Fine Crimped Woven Wire Mesh

Dutch Weave Stainless Steel 0.71mm Fine Crimped Woven Wire Mesh
Dutch Weave Stainless Steel 0.71mm Fine Crimped Woven Wire Mesh Dutch Weave Stainless Steel 0.71mm Fine Crimped Woven Wire Mesh

Large Image :  Dutch Weave Stainless Steel 0.71mm Fine Crimped Woven Wire Mesh

Product Details:
Place of Origin: Hebei, China
Brand Name: Xmesh
Certification: SGS
Model Number: QJ-0205
Payment & Shipping Terms:
Minimum Order Quantity: 200pcs
Packaging Details: Wood case or pallets
Delivery Time: 15-25days
Payment Terms: 30%TT in advance, Balance before loading
Supply Ability: 100rolls per month
Detailed Product Description
Size: 0.914m X 30m Material: UNS S31000 - 310
Weave: Dutch Woven Mesh: 40mesh
Technique: Woven Application: Woven Wire Mesh,Filters,Screen,Decorative Wire Mesh,Protecting Mesh
Type: Weave Wire Mesh,Wire Cloth,Crimped Wire Mesh,Rope Mesh Weave Style: Plain Weave,twill Weave,Plain/Twill Weave,plain/twill/dutch Weave,Dutch Weave
High Light:

stainless steel crimped wire mesh

,

30.5m Crimped Woven Wire Mesh

,

0.71mm Crimped Woven Wire Mesh

Trending Products Stainless Steel Crimped Wire Mesh - Dutch Weave Wire Mesh



Dutch Weave Wire Mesh is also known as stainless steel dutch woven wire cloth and stainless steel filter cloth. It is usually made of mild steel wire and stainless steel wire. Stainless steel dutch wire mesh is extensively utilized as filter fittings for the chemical industry, medicine, petroleum, scientific research units, due to its stable and fine filtration capability.



The apparent difference of reverse dutch weaving compared with standard Dutch weave lies in the thicker warp wires and fewer weft wires. Reverse dutch woven stainless steel wire cloth offers finer filtration and finds popular applications in petroleum, chemical, food, pharmacy, and other fields. Through constant technological innovation and improvement, we can produce stainless steel wire mesh of various specifications in reverse Dutch weaving patterns.



Product Feature

Properties of dutch wire mesh filtration, fine stability, high precision, with special filtration performance.



Product Description

Dutch wire mesh is made of high-quality stainless steel wire woven. The main feature is the warp and weft wire diameter and density of greater contrast, and therefore the net thickness and filtering accuracy and life will have a more significant increase than the average square mesh.



Specification

1, Available Material: Stainless steel SUS304, SUS304L, SUS316, SUS316L, copper, nickel, Monel, titanium, silver, plain steel, galvanized iron, aluminum and etc.

2, Size: Up to clients

3, Pattern design: up to clients, and we can offer a suggestion as well based on our experience.



Product Application

Widely used precision pressure filters, the fuel filter, vacuum filter, as filter materials, aerospace, pharmaceutical, sugaring, oil, chemical, chemical fiber, rubber, tire manufacturing, metallurgy, food, health research, etc industries.



Advantage

1, Adopt high-quality stainless steel, SUS304, SUS316, and etc. To ensure the high quality of the end products.

2, Strictly follow the worldwide advanced technical standards to produce all of our products.

3, High degree corrosion, excellent oxidation resistance, can be used for the long term.



Basic Info

Woven Type: Dutch Plain Weave, Dutch Twill Weave and Dutch Reverse

Mesh: 17 x 44 mesh – 80 x 400 mesh, 20 x 200 – 400 x 2700 mesh, 63 x 18 – 720 x 150 mesh, To accurately

Wire Dia.: 0.02 mm – 0.71mm, small deviation

Width: 190mm, 915mm, 1000mm, 1245mm to 1550mm

Length: 30m, 30.5m or cut to length minimum 2m

Wire Material: stainless steel wire, low carbon steel wire

Mesh Surface: clean, smooth, small magnetic.

Packing: Water-Proof, Plastic Paper, Wooden Case, Pallet

Min.Order Quantity: 30 SQM

Delivery Detail: 3-10 days

Sample: Free Charge



Plain Dutch Weave Wire Cloth
Mesh/Inch
(warp×weft)
Wire Dia.
warp×weft
(mm)
Reference
Aperture
(um)
Effective
Section
Rate%
Weight
(kg/sq.m)
7 x 44 0.71×0.63 315 14.2 5.42
12×64 0.56×0.40 211 16 3.89
12×76 0.45×0.35 192 15.9 3.26
10×90 0.45×0.28 249 29.2 2.57
8 x 62 0.63×0.45 300 20.4 4.04
10 x 79 0.50×0.335 250 21.5 3.16
8 x 85 0.45×0.315 275 27.3 2.73
12 x 89 0.45×0.315 212 20.6 2.86
14×88 0.50×0.30 198 20.3 2.85
14 x 100 0.40×0.28 180 20.1 2.56
14×110 0.0.35×0.25 177 22.2 2.28
16 x 100 0.40×0.28 160 17.6 2.64
16×120 0.28×0.224 145 19.2 1.97
17 x 125 0.35×0.25 160 23 2.14
18 x 112 0.35×0.25 140 16.7 2.37
20 x 140 0.315×0.20 133 21.5 1.97
20 x110 0.35 x 0.25 125 15.3 2.47
20×160 0.25×0.16 130 28.9 1.56
22 x 120 0.315×0.224 112 15.7 2.13
24 x 110 0.35×0.25 97 11.3 2.6
25 x 140 0.28×0.20 100 14.6 1.92
30 x 150 0.25×0.18 80 13.6 2.64
35 x 175 0.224×0.16 71 12.7 1.58
40 x 200 0.20×0.14 60 12.5 1.4
45 x 250 0.16×0.112 56 15 1.09
50 x 250 0.14×0.10 50 14.6 0.96
50×280 0.16×0.09 55 20 0.98
60 x 270 0.14×0.10 39 11.2 1.03
67 x 310 0.125×0.09 36 10.8 0.9
70 x 350 0.112×0.08 36 12.7 0.79
70 x 390 0.112×0.071 40 16.2 0.72
80×400 0.125×0.063 32 16.6 0.77
