Product Details:
Payment & Shipping Terms:
|
| Material: | STAINLESS STEEL WIRE | Type: | Rope Mesh, Ferrule Type Or Knotted Type |
|---|---|---|---|
| Application: | Protecting Mesh | Weave Style: | Plain Weave |
| Technique: | Woven | Model Number: | Steel Wire Rope Mesh |
| Processing Service: | Weave | Raw Material: | Stainless Steel 304 316, Galvanized Wire |
| Accessories: | All Could Be Provided | ||
| High Light: | stainless steel rope mesh,flexible stainless steel cable mesh |
||
1.Material:stainless steel wire (304,304L,316,316L etc)
2.Rope dia.:1.0mm-4.0mm
3.Popular Mesh Size: 1"*1", 1-1/2"*1-1/2",2"*2",3"*3",4"*4"
4.Structure:7x7 and 7x19 etc.
5.Fatigue resistance, impact resistance, breaking force, the overall structure of the rugged life of more than 30 years;
6.Boycott of the masticatory rodents and other pests (tensile strength of about 100-110000 PSI), good flexibility, won't hurt plumage or animal skin contact
7.Features: light weight, high strength, never rust, good softness, high fatigue strength, high impact resistance, large crushing force,
8.Application: animal zoo, building
steel wire rope mesh roll
9.Main Specifications:
| stainless steel wire rope mesh-zoo mesh specifications | ||||
| NO | structure | breaking force ( KN ) | wire diameter(MM) | opening (MM) |
| RX32115 | 7 X 19 | 7.38 | 3.2 | 115 X 115 |
| RX3290 | 7 x 19 | 7.38 | 3.2 | 90 x 90 |
| RX24102 | 7 x 7 | 4.18 | 2.4 | 102 x 102 |
| RX2490 | 7 x 7 | 4.18 | 2.4 | 90 x 90 |
| RX2476 | 7 x 7 | 4.18 | 2.4 | 76 x 76 |
| RX2451 | 7 x 7 | 4.18 | 2.4 | 51 x 51 |
| RX2078 | 7 x 7 | 3.17 | 2 | 78 x 78 |
| RX2066 | 7 x 7 | 3.17 | 2 | 66 x 66 |
| RX2051 | 7 x 7 | 3.17 | 2 | 51 x 51 |
| RX2038 | 7 x 7 | 3.17 | 2 | 38 x 38 |
| RX1676 | 7 x 7 | 2.17 | 1.6 | 76 x 76 |
| RX1651 | 7 x 7 | 2.17 | 1.6 | 51 x 51 |
| RX1638 | 7 x 7 | 2.17 | 1.6 | 38 x 38 |
| RX1531 | 7 x 7 | 2 | 1.5 | 31x 31 |
Pictures:
