100 Mesh Stainless Steel Wire Mesh Screen 150 Micron

100 Mesh Stainless Steel Wire Mesh Screen 150 Micron
100 Mesh Stainless Steel Wire Mesh Screen 150 Micron 100 Mesh Stainless Steel Wire Mesh Screen 150 Micron 100 Mesh Stainless Steel Wire Mesh Screen 150 Micron

Large Image :  100 Mesh Stainless Steel Wire Mesh Screen 150 Micron

Product Details:
Place of Origin: HeBei,China
Brand Name: QiJie
Certification: Certificate
Payment & Shipping Terms:
Minimum Order Quantity: 1 rolls
Price: Discuss
Packaging Details: Wooden carton
Delivery Time: within 7-30 days
Payment Terms: 30%TT
Supply Ability: 1500 Roll/Rolls per Week
Detailed Product Description
Type: Weave Wire Mesh, Wire Cloth, Crimped Wire Mesh, Rope Mesh, Welded Mesh Material: Stainless Steel Wire
Technique: Woven, Welded Mesh Application: Woven Wire Mesh, Filters, Screen, Decorative Wire Mesh, Protecting Mesh
Weave Style: Stainless Steel Wire, 316, 304, Copper, Plain Steel Galvanized Hole Shape: Square Hole, Round
Usage: Liquid Filter, Chmical Industry, Oil, Filtration, Filtering And Sieveing
High Light:

100 Mesh Stainless Steel Wire Mesh

,

150 Micron Stainless Steel Mesh Screen

,

Square Hole Micro Screen Mesh

100 Mesh Stainless Steel Wire Mesh Screen/Micro Screen Mesh/150 Micron Stainless Steel Mesh Screen



316 Advantages of stainless steel mesh:
8cr-12ni-2.5mo has excellent corrosion resistance, atmospheric corrosion resistance and high temperature strength due to the addition of Mo, so it can be used in harsh conditions, and it is less likely to be corroded than other chromium-nickel stainless steels in brine, sulfur water or brine. The corrosion resistance is better than that of 304 stainless steel mesh, and it has good corrosion resistance in pulp and paper production. Moreover, 316 stainless steel mesh is more resistant to ocean and aggressive industrial atmosphere than 304 stainless steel mesh.
304 Advantages of Stainless Steel Mesh:
304 stainless steel mesh has excellent corrosion resistance and intergranular corrosion resistance. In the experiment, it is concluded that 304 stainless steel mesh has strong corrosion resistance in nitric acid with concentration ≤65% below boiling
temperature. It also has good corrosion resistance to alkali solution and most organic and inorganic acids.



Specifications:
Material: 304 Stainless Steel
Mesh: 20 mesh / 40 mesh / 60 mesh / 80 mesh / 100 mesh
Size: 3'x100' (0.914mX30m) / 4'X100' (1.22mX30m) / 5'X100' (1.5mX30m) / 6'X100' (1.8mX30m)
Hole: 0.18mm
Wire Diameter: 120µm



please find the charts that illustrate the standard chemical composition of T 304 stainless steel and T 316 stainless steel. T 316 stainless steel is sometimes referred to marine grade because it offers a higher level of corrosion resistance, specifically in salt water environments.

T-304 Stainless Steel – Standard Chemical Composition (in %)

Alloy Carbon [C] Manganese [Mn] Phosphorus [P] Sulfur [S] Silicon [Si] Chromium [Cr] Nickel [Ni] Iron [Fe] Others, if Applicable
T-304 SS 0.08 Max 2.0 Max 0.045 Max 0.03 Max 1.00 Max 18.00–20.00 8.00–10.50 Balance Nitrogen [N] = 0.10 Max

T-316 Stainless Steel – Standard Chemical Composition (in %)

Alloy Carbon [C] Manganese [Mn] Phosphorus [P] Sulfur [S] Silicon [Si] Chromium [Cr] Nickel [Ni] Iron [Fe] Others, if Applicable
T-316 0.08 Max 2.00 Max 0.045 Max 0.03 Max 1.00 Max 16.00–18.00 10.00–14.00 Balance Mo = 2.00-3.00, N = 0.10 Max
Mo = Molybdenum; N = Nitrogen



Characteristic:
304/316/316L Stainless steel material, not easy to rust, sturdy and durable.
Bendable and maintain a curved shape, not as fragile as plastic mesh.
The grid is very small but thick enough.

stainless steel wire mesh



stainless steel wire mesh
