Product Details:
Payment & Shipping Terms:
|
| Material: | Black Wire, Spring Steel Wire, 65mn | Aperture: | 0.8 - 8 Mm |
|---|---|---|---|
| Size: | 1.5mx1.95m | Install: | Hooked |
| Surface Treatment:: | Galvanized Or Painted | Mesh Size: | 1mm - 100mm |
| Hole Type: | Square, Rectangular And Long Slot. | ||
| High Light: | Heat resistance crimped woven wire mesh,high manganese crimped woven wire mesh |
||
High Manganese 65mn Steel Wire Quarry Mine Crusher Sieve Screen Mesh Factory Price
Crimped wire mesh is made of cotton ginning machine after ginning after square meshesinto and new netting machine for different materials and different specifications of the metalwire woven wire mesh products, with many uses.
According to the different materials can also be called wire crimped wire mesh, galvanized crimped wire mesh, crimped wire mesh, black white steel Crimped Wire Mesh, stainless steel Crimped Wire.
Method of knitting cotton ginning net:
Using the method of knitting forming after the first bending.
Crimped wire mesh material:
Stainless steel wire, 301, 302, 304, 304L, 316, 316L, 321.
Product features:
Heat resistance, acid resistance, alkali resistance, corrosion resistance, abrasion resistance, wide and solid structure.
Product application:
Mainly used in food, chemical, pharmaceutical, mining, petroleum, metallurgy, machinery, building, door, crafts and other industries.
Please contact us as soon as possible if you are interested in our products. We'll try our best to supply the best service to you!
1. Double Crimp Woven Wire
Used for medium to heavy wire in relation to screen opening size.
2. Lock pre-crimp mesh
Unlike plain crimped mesh, lock crimped mesh is characterized by straight sections of wire connected by a well defined bump at the wire intersections, such a manner to actually lock the wires together, offering further assurance of no wire movement. Our lock crimp wire mesh is good in quality and competitive at price.
3. Flat Top Woven Wire
Flat top is similar to the lock crimp, but all of its crimping is offset to one side of the material. This creates a smooth top surface-with no high points-as all wires are woven on a single plane. Its bottom side, however, has crimp bumps approximately twice the height of lock crimp bumps. Flat top was originally created to allow for the smooth flow of materials over the surface and provide a flat face for use as backer screens. Flat top is ideal for aggregate sizing and sorting, agriculture, filtration, and heat-treating applications.
4. Intermdiate Crimp Woven Wire
Used in coarse weaves of lighter gauge woven wire to provide greater stability, tightness of weave and maximum rigidity. Very common in wire mesh openings larger than 1/2" (12.7mm).
Wire NO. (SWG) |
Wire diameter(mm) |
Hole (mm) |
Kg/m2 |
material |
22 |
0.71 |
0.14 |
3.3 |
Stainless steel wire |
19 |
1.00 |
1.0 |
1.45 |
Stainless steel wire |
6 |
4.8 |
2.06 |
12.8 |
Stainless steel wire |
6 |
4.8 |
3.15 |
8.9 |
|
6 |
4.8 |
2.5 |
10.8 |
Stainless steel wire |
14 |
2.0 |
0.3 |
11 |
Stainless steel wire |
14 |
2.0 |
1.0 |
4.6 |
Stainless steel wire |
14 |
2.0 |
1.1 |
4.6 |
|
8 |
4.05 |
1.06 |
15.8 |
|
25 |
0.50 |
0.077 |
2.6 |
|
23 |
0.61 |
0.08 |
3.7 |
Stainless steel wire |
24 |
0.55 |
0.1 |
2.7 |
|
24 |
0.55 |
0.126 |
2.4 |
Applications
Packing
Packing: In rolls, wrapped with waterproof paper then covered with hessian-cloth. Special packing may be arranged if necessary.
