Coil Drapery Wire Mesh Metal Mesh Curtain Decorative Wire Mesh

Large Image : Coil Drapery Wire Mesh Metal Mesh Curtain Decorative Wire Mesh

Product Details:

Place of Origin:	CHINA HEBEI
Brand Name:	Qijie
Model Number:	Qijie Decorative mesh

Payment & Shipping Terms:

Minimum Order Quantity:	5 m²
Price:	30USD/m²
Packaging Details:	wooden pallets
Delivery Time:	10 days
Payment Terms:	D/P
Supply Ability:	1000m²/month

Contact Now

Detailed Product Description

Technique:	Woven	Application:	Woven Wire Mesh,Decorative Wire Mesh
Type:	Weave Wire Mesh	Material:	Stainless Steel Wire/Aluminum Mesh

Metal Coil Drapery also called Metal coil curtain, the same with chain link curtain and ring mesh curtain, is a new type of decorative metal mesh curtain. It is made of high quality stainless steel, aluminum alloy and other alloy materials by special technology.

design	open area	cable wire dia.	cable pitch	bar dia.	bar pitch	thickness	wt
1	40%	1x1.8 mm	4 mm	1.5 mm	5.5 mm	5.1 mm	7.74kg/m2
2	43%	1x2.5 mm	6 mm	2 mm	8 mm	5.5 mm	7.87kg/m2
3	62%	2x2.75 mm	40 mm	4 mm	14.5 mm	9.5 mm	9.41kg/m2
4	37.20%	3x0.5 mm	3.5 mm	0.5 mm	1.4 mm	1.3 mm	2.4kg/m2
5	71%	3x1.6 mm	80 mm	2.5 mm	10 mm	5.7 mm	4.58kg/m2
6	65%	3x2 mm	80 mm	3 mm	10 mm	7 mm	6.67kg/m2
7	65.90%	3x2.75 mm	110 mm	4 mm	14.5 mm	10 mm	8.5kg/m2
8	67%	3x3 mm	110 mm	4 mm	14.2 mm	10 mm	8.6kg/m2
9	44.30%	4x0.75 mm	26.4 mm	1.5 mm	3 mm	3 mm	5.2kg/m2
10	62%	4x1 mm	36 mm	2 mm	6.6 mm	4 mm	4.55kg/m2
11	40%	4x2 mm	50 mm	3 mm	6 mm	7mm	11.2kg/m2
12	42%	4x2 mm	50 mm	3 mm	6 mm	7 mm	11.8kg/m2

Product name	Aluminum mesh curtain/ Metal Coil Drapery
Material	Aluminum alloys,stainless steel, iron , copper, etc.
Wire diameter	0.5mm-2.0mm, the common is 1.2mm
Aperture size	5mm-20mm, the commom is 5x5mm, 6x6mm
Colors	Silver, golden, brass yellow, black, gray, bronze, red, etc.
Rail	Straight type and curved type
Surface treatment	Polished natural,paint-spray and anodizing
Weight	1.2kg/m2 - 6 kg/m2 (depended by shape and material chosen)
Height and width	Can be customized
Application	Curtain-shower, door, window, house; Space divider-for home,office,hotel,supermarket, etc; For decoration- ceiling lamp, wall covering, display, light partitioning, trade fair exhibition; For protection-facade,enclosures,cladding,sun shades Screens & isolation - for dining hall, etc

Metal mesh curtain can be sprayed into almost any color, these are several commonly used colors. More colors are customizable, you can ask us for a color card or send us your request.

Coil Drapery Wire Mesh Metal Mesh Curtain Decorative Wire Mesh 6

Coil Drapery Wire Mesh Metal Mesh Curtain Decorative Wire Mesh 7 We can provide you with accessories and tracks, and the specifications of various styles can be customized.

Coil Drapery Wire Mesh Metal Mesh Curtain Decorative Wire Mesh 8
