Galvanized 3D Panel Fence 3D Curved Steel Welded Fence Curved Wire Fence V Mesh Wire Fence Security Fence
Welded Mesh Fencing is an economical and durable fencing type that suits a wide variety of applications.
The fence panels are typically constructed with rolled top and bottom profiles, which adds strength and durability to the fence panels, without adding additional weight. The design means the panels remain light weight and cost effective, which make weld mesh panels ideal for multiple applications.
Most commonly welded mesh panels are used for boundary fencing and secured compounds due to the added strength of the welded mesh design and heavier wire diameters, making it difficult to cut or damage.
Wire mesh fence is also known as safety mesh fence, wire mesh grating, galvanized fence, fencing panel and so on.
Material: Low carbon steel wire and other materials.
Process: Made through weaving, punching and welding.
Application: Fencing and protection for road, railway, airport, residence district, seaport, garden, feeding and husbandry.
Product Features: Corrosion resistant, age resistant, sunshine proof, weather proof.
Corrosion Form: Electric galvanized, Hot-dipped galvanized, PVC coated, Electric galvanized then PVC spraying, Electric galvanized then PVC coated.
| TYPE |
HEIGHT |
LENGTH |
WIRE DIAMETER |
MESH |
FOLDS NO. |
| ZH-01 |
0.6/0.63m |
2.0m
2.5m
|
Gal + Powder Coated 3.85mm/4.0mm
4.85mm/5.0mm
|
50*200
55*200
50*150
55*100
|
2 |
| ZH-02 |
1.0/1.03m |
2 |
| ZH-03 |
1.2/1.23m |
2 |
| ZH-04 |
1.5/1.53m |
Gal + PVC Coated
3.0mm/4.0mm
4.0mm/5.0mm
|
3 |
| ZH-05 |
1.7/1.73m |
3 |
| ZH-06 |
1.8/1.83m |
4 |
| ZH-07 |
1.9/1.93m |
3 |
| ZH-08 |
2.0/2.03m |
4 |
| ZH-09 |
2.4/2.43m |
4 |
| ZH-10 |
2.4/2.43m |
3m |
4.0mm/5.0mm |
4 |
Application
1. Home garden building wire mesh fencing
2. Residential wire mesh fencing
3. Filed wire mesh fencing
4. Animal wire mesh fencing
5. Supermarket parking wire mesh fencing
