Product Description
The rope mesh material is Stainless steel 304 316 304L 316L.
Wire structure common size: 7x7-the diameter is < 3mm,7x19>3mm.
Stainless steel rope mesh specification
| Wire rope diameter |
1.2mm,1.5mm,2.0mm,2.5mm,3.0mm,3.2mm,4.0mm |
| Mesh hole |
3x3cm,4x4cm,5x5cm,6x6cm,7x7cm,8x8cm etc. |
Don't understand how to mark the mesh size,let us use one drawing mark it. Common opening angle is 600,900.
1. Material of Stainless Steel Zoo Wire Mesh : Stainless steel 304,304L,316,306L etc.
| SS304 |
(%) C:≤0.07, Si :≤1.0, Mn :≤2.0, Cr :17.0-19.0, Ni :8.0-11.0, S :≤0.03, P :≤0.035 |
| SS316 |
(%) C:≤0.08, Si:≤1.00, Mn:≤2.00, P≤:0.035, S:≤0.03, Ni:10.0-14.0, Cr:16.0-18.5 |
| SS316L |
(%)C:≤0.03, Si:≤1.00, Mn:≤2.00, P:≤0.045, S:≤0.030, Cr:16.0～18.0, Ni:12.0～15.0 |
Recommended Monkey Enclosure Zoo Wire Mesh:
| Material |
Cable Diameter |
Hole Size |
Normal Break |
| SS304/316/316L |
3/32" (2.4MM) |
2.5" x 2.5" |
920 LBS |
| SS304/316/316L |
3/32" (2.4MM) |
2" x 2" |
920 LBS |
| SS304/316/316L |
5/64" (2.0MM) |
2.5" x 2.5" |
676 LBS |
| SS304/316/316L |
5/64" (2.0MM) |
2" x 2" |
676 LBS |
| SS304/316/316L |
1/8" (3.2MM) |
2" x 2" |
1600 LBS |
| SS304/316/316L |
1/8" (3.2MM) |
3" x 3" |
1600 LBS |
Stainless steel zoo wire is light, robust, and transparent. High-quality stainless steel cables and pressed ferrules are used for the production of the mesh and connected to a load-bearing and flexible structure. The curvature in the opposite direction of the stainless steel cables creates the exceptionally robust characteristics of the mesh can even stand up to heavy loads.
|
Rope Constructin
|
Rope Diameter
|
Opening Size
|
Breaking Force |
| |
Inch |
mm |
Inch |
mm |
KN |
| 7 × 19 |
1/8 |
3.2 |
4.7" × 4.7" |
120 × 120 |
7.38 |
| 7 × 19 |
1/8 |
3.2 |
4" × 4" |
102 × 102 |
7.38 |
| 7 × 19 |
1/8 |
3.2 |
3.6" × 3.6" |
90 × 90 |
7.38 |
| 7 × 19 |
1/8 |
3.2 |
3" × 3" |
76 × 76 |
7.38 |
| 7 × 19 |
1/8 |
3.2 |
2" × 2" |
51 × 51 |
7.38 |
| 7 × 7 |
3/32 |
2.4 |
4" × 4" |
102 × 102 |
4.18 |
| 7 × 7 |
3/32 |
2.4 |
3.6" × 3.6" |
90 × 90 |
4.18 |
| 7 × 7 |
3/32 |
2.4 |
3" × 3" |
76 × 76 |
4.18 |
| 7 × 7 |
3/32 |
2.4 |
2.4" × 2.4" |
60 × 60 |
4.18 |
| 7 × 7 |
3/32 |
2.4 |
2" × 2" |
51 × 51 |
4.18 |
| 7 × 7 |
5/64 |
2 |
3" × 3" |
76 × 76 |
3.17 |
| 7 × 7 |
5/64 |
2 |
2.4" × 2.4" |
60 × 60 |
3.17 |
| 7 × 7 |
5/64 |
2 |
2" × 2" |
51 × 51 |
3.17 |
| 7 × 7 |
5/64 |
2 |
1.5" × 1.5" |
38 × 38 |
3.17 |
| 7 × 7 |
1/16 |
1.6 |
3" × 3" |
76 × 76 |
2.17 |
| 7 × 7 |
1/16 |
1.6 |
2" × 2" |
51 × 51 |
2.17 |
| 7 × 7 |
1/16 |
1.6 |
1.5" × 1.5" |
38 × 38 |
2.17 |
| 7 × 7 |
1/16 |
1.6 |
1.2" × 1.2" |
30 × 30 |
2.17 |
| 7 × 7 |
1/16 |
1.6 |
1" × 1" |
25 × 25 |
2.17 |
| 7 × 7 |
3/64 |
1.2 |
2" × 2" |
51 × 51 |
1.22 |
| 7 × 7 |
3/64 |
1.2 |
1.5" × 1.5" |
38 × 38 |
1.22 |
| 7 × 7 |
3/64 |
1.2 |
1.2" × 1.2" |
30 × 30 |
1.22 |
| 7 × 7 |
3/64 |
1.2 |
1" × 1" |
25 × 25 |
1.22 |
Stainless steel rope mesh feature:
1. Good toughness,anti climb, shock resistance, not easy to deform,excellent cushioning.
2. Long service time,anti rust,structure strong,no need to maintain.
3. Beautiful, lucency, environment friendly.
4. Easy to install,light weight.
-
Technical Parameters:
| Technical Parameters |
Value |
| Product Name |
Cable Rope Mesh, Drop Safe Net, Zoo Mesh |
| Customization |
Available |
| Mesh Orientation |
Diamond |
| Type |
Inter-woven Mesh, Ferruled Mesh |
| Panel Size |
Customized In Width And Length |
| Material |
SS304, SS316, SS316L |
| Finished |
Polished |
| Breaking Load |
≥ 7.38 KN |
| Features |
Flexible, Durable, Corrosion Resistant |
| Mesh Hole Size |
40mm, 50mm, 60mm, 80mm, Customizable |
| Shipment |
Express, Air or Sea |
Applications:
With a minimum order quantity of 1m2, the price of CHANT-04-01 can be negotiated, and it is packaged in a wooden case. The delivery time is estimated to be 7 days, and payment terms are TT or L/C. CHANT-04-01 has a supply ability of 10,000m2 per week.
The balustrade cable mesh product has various product application occasions and scenarios. The CHANT-04-01 can be used as aviary wire netting, making it an ideal product for those who have an aviary or want to build one. The mesh can be used to create a safe and secure environment for birds, while still allowing them to move freely and have a clear view of their surroundings.
The CHANT-04-01 can also be used as a backpack bag rope. The mesh is strong and durable, making it an ideal product for those who need a sturdy and reliable rope for their backpack. The mesh is also lightweight, making it easy to carry around.
Another product application for the CHANT-04-01 is as zoo mesh. The mesh can be used to create animal enclosures that are safe and secure, while still allowing visitors to have a clear view of the animals. The mesh is also rust-resistant, making it ideal for use in outdoor enclosures.
Customization:
CHANT-04-01 Balustrade Cable Mesh
Place of Origin: China
Certification: CE ISO9000
Minimum Order Quantity: 1m 2
Price: can be negotiated
Packaging Details: wooden case
Delivery Time: 7 days
Payment Terms: TT L/C
Supply Ability: 10000m 2 /week
Type: Inter-woven Mesh, ferruled Mesh
Mesh Hole Size: 40mm, 50mm, 60mm, 80mm, Customizable
Features: Flexible, Durable, Corrosion Resistant
Breaking Load: ≥ 7.38 KN
Shippment: Express, Air Or Sea
