316 Marine Grade Safety Netting for Architecture Fence Stainless Steel Wire Rope Net

Large Image : 316 Marine Grade Safety Netting for Architecture Fence Stainless Steel Wire Rope Net

Product Details:

Place of Origin:	Hebei, China
Brand Name:	QIJIE
Certification:	CE,SGS,ISO
Model Number:	SW-004

Payment & Shipping Terms:

Minimum Order Quantity:	10 square meters
Packaging Details:	wooden case
Delivery Time:	10-15 working days
Payment Terms:	30%TT in advance, Balance before loading
Supply Ability:	3000 m2/month

Contact Now

Detailed Product Description

Material:	STAINLESS STEEL WIRE	Type:	Rope Mesh, Ferrule Type Or Knotted Type
Application:	Protecting Mesh	Weave Style:	Plain Weave
Technique:	Woven	Model Number:	Steel Wire Rope Mesh
Processing Service:	Weave	Raw Material:	Stainless Steel 304 316, Galvanized Wire
Accessories:	All Could Be Provided	Email:	Devin@industrialmetalmesh.com
Whatsapp:	+8615369013183
Highlight:	316 marine grade safety netting , stainless steel wire rope fence , architectural stainless steel mesh net

316 Marine Grade Safety Netting for Architecture Fence Stainless Steel Wire Rope Net

Stainless Steel Wire Rope Mesh Netting, Cable Mesh Net

Stainless steel cable mesh is made from stainless steel wire rope in various material type like AISI 304 , AISI 316 , AISI 316L etc.

The selected wire rope has two main strand structures:7*7 and 7*19. Generally, when the diameter of the steel wire rope is less than 2.5mm, the strand structure is 7*7, and when it is longer than 2.5mm, the strand structure is 7*19.

The ferrule material is usually stainless steel, sometimes aluminum, copper, and other materials are used. In addition, we can also oxidize or spray the surface of the stainless steel cable mesh according to customer needs.

Stainless Steel Wire Rope Mesh Netting, Cable Mesh Net

Also called SS cable mesh) made of high quality stainless steel wire twisted together, with the features of extremely anti-corrosion and resistant to UV rays, has a long lifespan in the harsh environments. And its largest benefit is particular resilience and flexibility.

Item No.s	Cable Diameter		Mesh Opening Size(W×H)
	inch	mm	inch	mm
BZ-32120F	1/8	3.2	4.75 x 8.23	120 x 207.8
BZ-32102F	1/8	3.2	4 x 6.9	102 x 176.7
BZ-3290F	1/8	3.2	3.55 x 6.15	90 x 156
BZ-3276F	1/8	3.2	3 x5.2	76 x 131.6
BZ-3251F	1/8	3.2	2 x3.46	51 x88.3
BZ-24102F	3/32	2.4	4x6.9	102x176.7
BZ-2490F	3/32	2.4	3.55x6.15	90x 156
BZ-2476F	3/32	2.4	3 x 5.2	76x 131.6
BZ-2460F	3/32	2.4	2.4x 4.16	60x 104
BZ-2451F	3/32	2.4	2x3.46	51 x 88.3
BZ-2076F	5/64	2.0	3 x 5.2	76 x 131.6
BZ-2060F	5/64	2.0	2.4x 4.16	60 x 104
BZ-2051F	5/64	2.0	2 x 3.46	51 x 88.3
BZ-2038F	5/64	2.0	1-1/2 x 2.6	38 x 65.8
BZ-1676F	1/16	1.6	1.2 x2.08	76 x 131.6
BZ-1651F	1/16	1.6	2x 3.46	51 x 88.3
BZ-1638F	1/16	1.6	1-1/2 x 2.6	38 x 65.8
BZ-1630F	1/16	1.6	1.2x2.08	30 x 52
BZ-1625F	1/16	1.6	1 x 1.73	25.4 x 44
BZ-1238F	3/64	1.2	1-1/2x2.6	38 x 65.8
BZ-1230F	3/64	1.2	1.2 x 2.08	30 x 52
BZ-1225F	3/64	1.2	1 x 1.73	25.4 x 44
BZ-1220F	3/64	1.2	4/5 x 1.39	20 x 34.6

316 Marine Grade Safety Netting for Architecture Fence Stainless Steel Wire Rope Net 0

Applications:
1. Steel Mesh Balustrade - bridge, stair, balcony, path
2. Cable Mesh - Excellent Solution to Safety
3. Safety Net - Structural Measure to Prevent Suicide
4. Helipad Safety Net - Modular Heliport Webbing
5. Cable Zoo Mesh - Solution to Enclosing Most Animals
6. Aviary Netting - Lightweight, Durable and Long Lasting
7. Green Facade - Cable System for Most Climbing Plants

Advantages

High-Strength Construction: Durable 304/316 Stainless Steel ensures longevity and reliability.

Exceptional Stability: Multiple junction points and high-strength closed ferrules provide robust support.

Superior Corrosion Resistance: Perfect for heavy-duty plant support in various environments.

Professional Factory: Over 16 years of experience guarantees high-quality and efficient production.

Customizable Packaging: Special packages can be tailored to meet specific customer needs.

316 Marine Grade Safety Netting for Architecture Fence Stainless Steel Wire Rope Net 1

316 Marine Grade Safety Netting for Architecture Fence Stainless Steel Wire Rope Net 2
