Fully Automatic Galvanized High Tensile Steel Wire Winding Net Production Line

Large Image : Fully Automatic Galvanized High Tensile Steel Wire Winding Net Production Line

Product Details:

Place of Origin:	China
Brand Name:	Qijie
Certification:	sgs
Model Number:	CNC knitting machine

Payment & Shipping Terms:

Minimum Order Quantity:	1pcs
Price:	Discuss
Packaging Details:	wood case, steel pallet
Delivery Time:	15-18days
Payment Terms:	L/C, T/T
Supply Ability:	15pcs

Contact Now

Detailed Product Description

Weldingspeed:	20 - 60 Times Per Minute	Motor Power:	11KW
Productname:	Wire Mesh Machine	Machinetype:	Automatic Wire Mesh Knitting Machine
Voltage:	380V	Warranty:	1 Year
Power Source:	Electric	Powersupply:	380V, 50Hz, 3 Phase
Highlight:	automatic galvanized wire winding production line , high tensile steel wire mesh machine , galvanized wire net manufacturing line

Fully Automatic Galvanized High Tensile Steel Wire Winding Net Production Line

Automatic production line for manufacturing MZP wire barriers, complete with all necessary equipment for continuous production.

Required specifications:

• Wire diameter: 0.5 mm / 0.6 mm / 0.8 mm / 0.9 mm

• Production speed: not less than 20 meters per minute

• Automatic wire feeding system

• Automatic winding/coiling system

• Maximum wire coil weight: up to 35 kg

• Installed power: not less than 2.1 kW

• Power supply: 380 V, 50 Hz (please specify if modification is required)

• PLC control with touch screen interface

• English operation software and user manual

• Complete set of tools and spare parts for commissioning

Compared with manual weaving, the quality of each process of the product is stable.

It has a wide range of applications and can customize the total number of layers of woven products.

Easy to operate,featuring PLC-programmable control and 9-axis servo motor for precise positioning.Touch screen operation is more flexible.

1	Automatic High Tensile Twisted Wire Mesh Production Line
2	WIRE DIAMETER	0.5mm 0.6mm 0.8mm 0.9mm
3	MESH WIDTH	10101.1m
4	MESH HOLE SIZE	As per requirements in customer's picture
5	WORKING SPEED	25m/min
6	MAIN MACHINE SIZE	1750017001650MM
7	OVERALL WORKING DIMENSIONS (INCLUDING WIRE UNCOILER)	2100030001650MM
8	MAIN MACHINE WEIGHT	AROUND 4.5 TONS
9	POWER	220V,50HZ,Single Phase

knitting wire mesh machine

Fully Automatic Galvanized High Tensile Steel Wire Winding Net Production Line
