| Design Style: | Contemporary | Frame Material: | Metal |
|---|---|---|---|
| Metal Type:: | Iron | Frame Finishing: | Pvc Coated |
| Feature: | Easily Assembled | Usage: | Garden Fence, Highway Fence, Sport Fence, Farm Fence |
| Type: | Security Fence, Fence Gates | Service: | Instruction Book, Video Of Installation, Product Marketing |
| Product Name: | Steel Fence | Size: | 1.5*2m |
| Wire Diameter: | 4mm | Mesh Size: | 60*60mm |
| High Light: | 55x200mm curved wire fence,contemporary assembled curved wire fence |
||
| Code | H (mm) | W (mm) | Mesh (mm) | Horizontal wire | Vertical Wire | No.of V |
| 7111230 | 1230(4.00ft) | 2500(8.20ft) | 55x200(2.17"x8") | 4.00 | 4.00 | 2 |
| 7111430 | 1430(4.70ft) | 2500(8.20ft) | 55x200(2.17"x8") | 4.00 | 4.00 | 2 |
| 7111730 | 1730(5.70ft) | 2500(8.20ft) | 55x200(2.17"x8") | 4.00 | 4.00 | 3 |
| 7111930 | 1930(6.34ft) | 2500(8.20ft) | 55x200(2.17"x8") | 4.00 | 4.00 | 3 |
| POST-58x80 | ||||
| Code | H (mm) | Depth(mm) | Section (mm) | Wall thick(mm) |
| 7211600 | 1600(5.25ft) | 370(1.21ft) | 58X80(2.29"x3.15") | 1.0(19GA) |
| 7211900 | 1900(6.25ft) | 470( 1.54ft) | 58X80(2.29"x3.15") | 1.0(19GA) |
| 7212200 | 2200(7.22ft) | 470( 1.54ft) | 58X80(2.29"x3.15") | 1.0(19GA) |
| 7212400 | 2400(7.87ft) | 670(2.20ft) | 58X80(2.29"x3.15") | 1.0(19GA) |
| 7212600 | 2600(8.53ft) | 670(2.20ft) | 58X80(2.29"x3.15") | 1.0(19GA) |
| POST-70X100 | ||||
| Code | H (mm) | Depth(mm) | Section (mm) | Wall thick(mm) |
| 7221900 | 1900(6.25ft) | 470(1.54ft) | 70X100(2.76"x3.94") | 1.0(19GA) |
| 7222200 | 2200(7.22ft) | 470(1.54ft) | 70X100(2.76"x3.94") | 1.0(19GA) |
| 7222400 | 2400(7.87ft) | 670(2.20ft) | 70X100(2.76"x3.94") | 1.0(19GA) |
| 7222600 | 2600(8.53ft) | 670(2.20ft) | 70X100(2.76"x3.94") | 1.0(19GA) |
| Code | H (mm) | SINGLE GATE | Vertical Wire | No.of V | ||
| Opening (mm) | Mesh (mm) | Horizontal wire | ||||
| 7311230 | 1230(4.00ft) | 1000(3.28ft) | 55x200 (2.17"x811) |
5.00 | 5.00 | 0/2 |
| 7311430 | 1430(4.70ft) | 1000(3.28ft) | 55x200 (2.17"x8") |
5.00 | 5.00 | 0/2 |
| 7311730 | 1730(5.70ft) | 1000(3.28ft) | 55x200 (2.17"x811) |
5.00 | 5.00 | 0/3 |
| 7311930 | 1930(6.34ft) | 1000(3.28ft) | 55x200 (2.17"x8") |
5.00 | 5.00 | 0/3 |
| DOUBLE GATE | ||||||
| Code | H (mm) |
Opening (mm) | Mesh (mm) | Horizontal wire | Vertical Wire | No.of V |
| 7321230 | 1230 (4.00ft) |
3000 (9.85ft) |
55x200 (2.17"x8") |
5.00 | 5.00 | 0/2 |
| 7321430 | 1430 (4.70ft) |
3000 (9.85ft) |
55x200 (2.17"x8") |
5.00 | 5.00 | 0/2 |
| 7321730 | 1730 (5.70ft) |
3000 (9.85ft) |
55x200 (2.17"x8") |
5.00 | 5.00 | 0/3 |
| 7321930 | 1930 (6.34ft) |
3000 (9.85ft) |
55x200 (2.17"x8") |
5.00 | 5.00 | 0/3 |
Packing:
