Green Security Welded Wire Mesh Fence 3D Welded Wire Mesh Curved Fence
Product Description:
Curvy welded fence, also known as 3D security fence, is a kind of specially designed welded wire mesh with V-shaped bending curves in its longitudinal direction.
It is made of high quality carbon steel wires where wires in the horizontal and vertical direction are welded at their junctions to provide a rigid wire mesh fence.
Generally, the number of V-shaped curves varies as the height of welded wire mesh varies.
Its attractive appearance, rigid structure and excellent visibility make it become a popular security fence that is widely used in railways, airports, schools, factories, residential areas, gardens, parks, sports stadiums, etc.
Surface treatment
Galvanized and Powder coating
| Height | 630 mm, 830 mm, 1030 mm, 1230 mm, 1430 mm, 1530 mm, 1630 mm, 1730 mm, 1830 mm, 1930 mm, 2030 mm, 2230 mm, 2430 mm |
| Width | 2000 mm, 2500 mm, 2900 mm |
| Wire Diameter | 3.0 mm, 3.5 mm, 4.0 mm, 4.5 mm, 5.0 mm |
| Mesh Opening | 50 × 100 mm, 50 × 150 mm, 50 × 200 mm, 75 ×100 mm, etc |
| Clamp | metal clamp/anti-UV plastic clamp/ no clamp (for peach post) |
| Post | Round post (48 OD × 1.5/2.0 mm, 60 OD × 1.5/2.0 mm); Square post (50 × 50 × 1.5/2.0 mm, 60 × 60 × 1.5/2.0 mm, 80 × 80 × 1.5/2.0 mm); Rectangular post (40 × 60 × 1.5/2.0 mm, 40 × 80 × 1.5/2.0mm, 60 × 80 × 1.5/2.0 mm, 80 × 100 × 1.5/2.0 mm) |
| Post Cap | metal cap / anti-UV plastic cap |
| All colors are available in Ral; | |
| Other materials and specifications are available upon request. | |
| If the fence height falls between 630 mm and 1430 mm, it will have 2 folds; if the fence height falls between 1530 mm and 1930 mm, it will have 3 folds; if the fence height falls between 2030 and 2430, it will have 4 folds as shown below. | |
Applications of PVC 3D Welded Wire Mesh:
The PCV 3D welded wire mesh panels are commonly made of low carbon steel wire or galvanized wire,and then coated after being welded. However,the material of galvanized wire is much cost and stronger than low carbon steel wire.
Specifications of Galvanized 3D Welded Wire Mesh Panel:
Welded Wire curve fence is a new product popular in many developed countries.It is beautiful and convenient
in installation.The panels are made of wire with diameters ranging from 2.0 mm to 6.0 mm, which ensure a very high stiffness of the fence. The panels up to 2000mm, 2500 mm,3000mm wide and with heights ranging from 630 mm to 2430 mm.
Security fencing also called 3D security fence, and wire mesh fence, is widely used in garden, factory, railway, farmland and residence. Curved wire mesh fence can supply strongth and rigidity. Besides curves varies according to the fence height to produce optimum strength.
Advantages of Galvanized 3D Welded Wire Mesh Panel:
1. Aesthetics beauty looking.
2. Wild scope of using.
3. Thick coated with rust resistance.
4. Economic and long service life.
Post and all kits:
We provide posts and its all kits for the galvanized 3D welded wire mesh fence, and the size can be customized as well.
metal clamps
metal clamps-02
Workshop&Packing:
Qijie Wire Mesh MFG Co.,ltd is a professional manufacturer of fences, wire mesh products with more than 20 years experience. Welcome to visit our factory located in Anping city at any time!
