Material: | Copper Coated Wire | Wire Diameter: | 2.25mm X 0.5mm |
---|---|---|---|
Coil Weight: | 2.5 Kgs / Coil | Packing: | Plastic Film Inside, Hessian Cloth Outside |
Tensile Strength: | 350 - 550 MPa | ||
Highlight: | binding wire gauge,galvanized tie wire |
2.25x0.5mm Copper Coated Flat Stitching Wire for Carton Cardboard Boxes
We are leading manufacturer and exporter of Copper Coated Steel Wire.Clients can avail from us superior quality Copper Coated Steel Wire wire which is mainly used in the brush industry.
Galvanized binding wire, also known as galvanized steel wire, finds most uses in binding of construction materials or weaving of galvanized wire mesh products.
COPPER COATED GALVANIZED FLAT STITCHING WIRE:
Wire Gauge Type:16# 17# 18# 20# 21#
Wire Width:2.15mm---1.1mm Wire
Thickness:1.5MM---0.3MM
Nails Coil Weight:2.5kg
Use: For packing of cartons.
Note: Copper coated flat wire and electro galvanized flat wire can be made flat, triangle or trapezoid type.
Galvanized Flat Stitching Wire without Copper Coating:
Material: high quality low carbon steel wire
Surface treatment: galvanized or copper coated
Wire diameter: 0.1mm-5.0mm
Wire Length per coil: 20m-500m
Weight per coil:0.5kg-100kg or as your requirement
Packing: plastic reel ,plastic bag ,carton box or as your requirement
Loading quantity in 20'container:20-25tons
Grade | Industrial Grade |
Conductor Type | Solid |
Packing Type | Bundle, carton Box |
Coating | Copper Coated |
Yield Strength | More than 400 Mpa |
Diameter | 2.0mm - 5.0mm |
Materials: Low carbon steel, medium carbon steel or high carbon steel.
Carton Stitching Flat Wire
Packing: 2kg/coil, 2.5kg/coil without spool or carboard
20kg/carton,25kg/carton
Specification
16#(2.15*0.75mm) |
17#(2.0*0.8mm) |
18# (1.95*0.75mm) |
20# (1.35*0.65mm) |
22#(1.15*0.55mm) |
Tolerance is 0.02mm.
Features:
Galvanized Flat Wire for Stitching Uses |
Steel Flat Wire with Zinc Coating Galvanized |
Copper Coated Galv. Stitching Wire |
Copper Coated Galvanized Flat Wire for Stapling |
Galvanized Wire Material for Processing of Stitching Wire:
We can supply electro galvanized iron wire processed with low/hign carbon steel wire, through drawing and electric galvanizing, for processing of stitching wire.
Technical Information:
Material: super carbon steel Electro Galvanized Wire, Zinc coating: 10g/m2—40g/m2
The standard Wire gauge from BWG8—BWG33
Tensile Strength is 300-550Mpa, 650-1300Mpa
Firmed Coating Layer
Super in corrosion resistance
The Single roll wire without any inter-cuts or breaks
Application:
Low carbon galvanized wire is used in weaving wire mesh, binding, construction building, while the high carbon galvanized wire is made for cotton packing, etc.
Production Process of Electro Galvanized Iron Wire:
Steel rod coil -- Wire Drawing -- Wire Annealing--Rust Removing-- Acid Washing-- Boiling-- Drying-- Zinc Feeding-- Wire Coiling
Copper Coated Stitching Wire
