Welded 1x1 Inch 100mm Galvanized Wire Fence Panels

Welded 1x1 Inch 100mm Galvanized Wire Fence Panels
Welded 1x1 Inch 100mm Galvanized Wire Fence Panels

Large Image :  Welded 1x1 Inch 100mm Galvanized Wire Fence Panels

Product Details:
Place of Origin: Hebei, China
Brand Name: XMESH
Certification: SGS
Model Number: welded mesh panel
Payment & Shipping Terms:
Minimum Order Quantity: 200pcs
Packaging Details: pallets
Delivery Time: 15-25days
Payment Terms: 30%TT in advance, Balance before loading
Supply Ability: 1000pieces
Detailed Product Description
Type: Welded Wire Mesh Material: 201,202,304,304L,316,316L
Wire Diameter: 4-12mm Surface Treatment: Hot Dipped Galvanized Or Powder Coated
Feature: Good Integrity And A Competitively Long Service Life Aperture: 100mm Hole Opening
High Light:

1x1 galvanized wire fence panels

,

1x1 galvanized welded wire panels

,

100mm galvanized wire fence panels

1inch X 1inch Galvanized Welded Wire Mesh Panels In Various Mesh Hole Sizes



Welded Wire Mesh is known as welded wire or welded mesh by some customers. The structure of this kind of wire mesh is strong, lasting and rust-resistant. It is galvanized after welding. Two ways of galvanization: hot dipped( hot galvanized) & cold(electric) galvanized.

PVC coated welded wire mesh is made of quality welded low carbon steel wire mesh galvanized before,then coated with PVC powder or PE powder.The coated layer is even,strong adhere siveness and bright luster with long live good anti-corrosive property. All kinds of colors can be coated according to customers' special requirements.

Varieties available:Electric galvanized hot-dipped PVC coated.
Width:3',4',5',6',7';Packing,other width,length specification can be at buyer's option.

Welded wire mesh panels are a range of galvanized steel metal mesh sheets supplied in various mesh hole sizes.



Mesh hole sizes:
1" x 1" (1inch x 1inch) / 25mm x 25mm
2" x 2" (2 inch x 2 inch) / 50mm x 50mm
3" x 3" (3inch x 3inch) / 75mm x 75mm
Weld wire mesh sheets are manufactured using galvanized wire or cold drawn wire from BWG14(2.0MM) to BWG6 (5MM) . Our panels are strong and long lasting.



Typical Welded Steel Mesh Panels Uses:

Dog Fencing
Animal enclosures
Aviaries
Bird Cages
Pet hutches
Cat fences
Pond covers / pond protection
Garden Fencing
Due to the hot-dipped galvanized processes, sometimes the welded wire mesh panels have a rough texture which should be taken into consideration when purchasing for certain applications.





Premium and Standard Panels:
Hebei Shining Wire Mesh Co.,Ltd can produce below kinds of panel.
1.Electro galvanized before welded wire mesh, hot dipped galvanized before welded wire mesh. The raw material is galvanized wire ,meaning that each individual wire is galvanized then welded together to form the panel.
This is a process in which the steel is coated in a protective coating to help the steel resist
against corrosion and rust.
This is a more economical process however it does have a small risk that the welding process may remove some of the galvanized coating.
2.Galvanized after welded wire mesh. It made from black annealed wire or cold drawn wire.
It’s galvanized after coating, there is 100% coverage, all parts of panel are protective coating.





Specification List of Welded Wire Mesh:
Opening
Wire Diameter<BWG>
In inch
In metric unit(mm)
1/4" x 1/4"
6.4mm x 6.4mm
22,23,24
3/8" x 3/8"
10.6mm x 10.6mm
19,20,21,22
1/2" x 1/2"
12.7mm x 12.7mm
16,17,18,19,20,21,22,23
5/8" x 5/8"
16mm x 16mm
18,19,20,21,
3/4" x 3/4"
19.1mm x 19.1mm
16,17,18,19,20,21
1" x 1/2"
25.4mm x 12.7mm
16,17,18,19,20,21
1-1/2" x 1-1/2"
38mm x 38mm
14,15,16,17,18,19
1" x 2"
25.4mm x 50.8mm
14,15,16
2" x 2"
50.8mm x 50.8mm
12,13,14,15,16
Technical Note:
1.Standard roll length: 30m;width: 0.5m to 1.8m
2.Special sizes available at request
3.Packing: in waterproof paper in rolls. Custom packing available at request.

Galvanized Fencing Mesh:
Opening
Wire Diameter<BWG>
In inch
In metric unit(mm)
2" x 3"
50mm x 75mm
2.0mm,2.5mm,1.65mm
3" x 3"
75mm x 756mm
2.67mm,2.41mm,2.11mm,1.83mm,1.65mm
2" x 4"
50mm x 100mm
2.11mm,2.5mm
4" x 4"
100mm x 100mm
2.0mm,2.5mm
Technical Note:
1.Standard roll length: 30m;width: 0.5m to 1.8m
2.Special sizes available at request
3.Packing: in waterproof paper in rolls. Custom packing available at request.

PVC Coated Welded Mesh:
Opening
Wire Diameter<BWG>
In inch
In metric unit(mm)
1/2" x 1/2"
12.7mm x 12.7mm
16,17,18,19,20,21
3/4" x 3/4"
19mm x 19mm
16,17,18,19,20,21
1" x 1"
25.4mm x 25.4mm
15,16,17,18,19,20
Technical Note:
1.Standard roll length: 30m;width: 0.5m to 1.2m
2.Special sizes available at request
3.Packing: in waterproof paper in rolls. Custom packing available at request.
