| Size: | 2400 H X 2300 L | Surface Treatment: | Galvanized |
|---|---|---|---|
| IPE Post Size: | 100x55mm | Pales: | W Section |
| Type: | Fencing,Trellis & Gates,protective Grille Profile Or Clamping Profile | Feature: | Easily Assembled,Eco Friendly,Waterproof,Rot Proof,Rodent Proof |
| Metal Type: | Iron,Steel,Iron Or Galvanized | Frame Finishing: | PVC Coated,Powder Coated,anodized |
| Frame Material: | Metal | Pressure Treated Wood Type: | Heat Treated,Nature |
| Color: | White,black,Green,blue,red | Surface Treatment: | Galvanized+PVC Coated,Electric\Hot-Dipped Galvanized+PVC\Powder Coated |
| Application: | Fence Mesh,Used,Garden,Residential | Usage: | Protection,Garden Decoration,building,Garden Fence/highway/airport |
| High Light: | w profile galvanized palisade fence,hot dipped galvanized palisade fence,cell tower galvanised palisade fencing |
||
W Profile 2400HX2300L Hot Dipped Galvanized Palisade Fence For Cell Tower
Palisade Fence, as effective security fencing, The forbidding appearance, inherent strength and high damage resistance make the palisade fencing one of the best choices of premise protection.
Designed with smooth surface, rigidity structure, sharp prongs and narrow pale spacing, the palisade fences are normally considered to be difficult even impossible to climb, straddle, grab and gain foot-hold. Thereby, it effective deters would to be intruders and trespassers, protects your assets, office and factory from damages.
| Type | Pale size | Pale Thickness | Height | Width | Angle Rail | Post | Post Length |
| PALES-L | 30X3040X40 40X40 50X50 | 3.0-6.0 | 1800 | 2750 |
L40X40X4.0 L50X50X4.0 L50X50X5.0 L50X50X6.0 |
IPE100x55 IPE120x74 SHS80x80x3.0 SHS100x100x3.0 |
2400 |
| 2100 | 2700 | ||||||
| 2400 | 3000 | ||||||
| 3000 | 3700 | ||||||
| 4000 | 4700 |
Min order: 100PCS
Payment Terms:
Supply ability: 400TON/MONTH
Delivery time: 30
Packages: Pallet
Tower fencing is the most popular choice for locations requiring a higher level of security and vandal resistance, and can be seen protecting premises of many different types throughout the UK. Steel palisade fencing is especially popular for schools and industrial sites because of its high damage resistance and the fact that it is so difficult to climb.
As tower fencing suppliers, Anping County Hua Guang supply both the W section style of palisade fencing and the D section style of palisade fencing, with the integrity of the palisade fence being maintained by the two horizontal rails that are used as standard in palisade fences up to three metres high. However, we can supply other heights of palisade fencing as required
Specification
| Height (mm) |
Width (mm) |
Pales
(mm)
|
PCS of Pales | Angle rail (mm) |
PCS of rail | H Post | PCS of post |
| 1800 | 2750 | 71x2.0x1800 | 17 | 50x50x4x2750 | 2 | 100x55x2200 | 1 |
| 2200 | 2750 | 71x2.5x2200 | 17 | 50x50x4x2750 | 2 | 100x55x2600 | 1 |
| 2400 | 3000 | 71x3.0x2400 | 17 | 50x50x5x2750 | 2 | 100x55x3000 | 1 |
Pales- "W" section Most using type for palisade fencing as vertical pales ,it is always the first choice for the pales .
| Width | Thickness | Surface Treatment | Head | Height |
| 68mm - 70mm |
2.0mm 2.5mm 3.0mm |
Galvanized and Electrostatic polyester powder coated or hot dipped galvanized |
Single point Triple point |
1200mm |
| 1500mm | ||||
| 1800mm | ||||
| 2000mm | ||||
| 2100mm | ||||
| 2400mm | ||||
| 2700mm | ||||
| 3000mm |
Comparing with "W" profile pales , this type is more economical.
| Width | Thickness | Surface Treatment | Head | Height |
| 68mm - 70mm |
2.0mm 2.5mm 3.0mm |
Galvanized and Electrostatic polyester powder coated or hot dipped galvanized |
Single point Triple point |
1200mm |
| 1500mm | ||||
| 1800mm | ||||
| 2000mm | ||||
| 2100mm | ||||
| 2400mm | ||||
| 2700mm | ||||
| 3000mm |
Its cost is similar with "D" profile ,and more simple than "D" profile.
| Width | Thickness | Surface Treatment | Head | Height |
| 40x40 | 2.0mm - 3.0mm |
Galvanized and Electrostatic polyester powder coated or hot dipped galvanized |
Single point | 1200mm |
| 1500mm | ||||
| 1800mm | ||||
| 2000mm | ||||
| 2100mm | ||||
| 2400mm | ||||
| 2700mm | ||||
| 3000mm |
