Odm And Oem Ss 305 Galvanized Steel Wire Rope

Odm And Oem Ss 305 Galvanized Steel Wire Rope
Odm And Oem Ss 305 Galvanized Steel Wire Rope Odm And Oem Ss 305 Galvanized Steel Wire Rope Odm And Oem Ss 305 Galvanized Steel Wire Rope

Large Image :  Odm And Oem Ss 305 Galvanized Steel Wire Rope

Product Details:
Place of Origin: China
Brand Name: qijie
Certification: CCS
Model Number: 6x36ws+IWRC
Payment & Shipping Terms:
Minimum Order Quantity: 1rolls
Packaging Details: Wooden Reel/coil/roll/Z2 Packing
Delivery Time: 25-30days
Payment Terms: 30%TT in advance, Balance before loading
Supply Ability: 1000meters per month
Detailed Product Description
Material: Galvanized Steel Wire Structure: 6x36ws+IWRC
Usage: Construction Material Packing: Wooden Reel/coil/roll/Z2 Packing
High Light:

odm galvanized steel wire rope

,

ss 305 galvanized steel wire rope

,

oem galvanised steel wire rope 3mm

Steel Cable Steel Wire Rope 6X36ws+Iwrc, 48mm, Ungalv, EIPS, API-9A Galvanized Steel Cable ODM&OEM Factory



Galvanized steel wire ropes feature compressed zinc coating for providing excellent corrosion resistance. With higher break strength yet lower price than stainless steel, galvanized steel wire ropes are widely used in general engineering applications such as winches and security ropes.





  • Bright steel wire ropes mean no surface treatment is applied to the rope. Therefore, they have the lower price among these three wire ropes. Generally, they are fully lubricated to protect the rope from rust and corrosion.
  • Galvanized steel wire ropes feature compressed zinc coating for providing excellent corrosion resistance. With higher break strength yet lower price than stainless steel, galvanized steel wire ropes are widely used in general engineering applications such as winches and security ropes.
  • Stainless steel wire ropes, made of quality 304, 305, 316 steels, are the most corrosive type for marine environments and other places subjected to salt water spray. Meanwhile, bright and shiny appearance can be maintained for years rather than dull as galvanized steel wire ropes.





A plan of steel wire rope with fiber core.FC stands for fiber core, made of natural or synthetic fiber, which can provide excellent flexibility and resistance to contact pressure. The fiber core can store lubrication to reduce the friction between wire strands effectively. Meanwhile, the fiber core makes the rope lower deformable with low elastic rope elongation.









A plan of steel wire rope with wire strand core.WSC is abbreviation of wire strand core. WSC ropes features better heat resistance than FC ropes, meanwhile, increase metallic section provide added 15% of strength. However, WSC steel ropes are less flexible than those with fiber cores.











A plan of steel wire rope with independent wire rope core.IWRC is short for independent wire rope core, which strengths the rope, reduce tensile stress in individual wires as well as makes the ropes more resistant to crushing. At the same time, IWRC wire ropes have the maximum heat resistance than others FC or WSC ropes.











A plan of cross laid steel wire rope.Cross laid wire rope means each wire of different layers contacts in points and has relatively large spaces between wires. It is extremely flexible and generally used in slings. Compared with parallel laid wire rope, this one has smaller contact area which makes it easier to fail due to fatigue and shear over time.













A plan of parallel laid steel wire rope.Parallel laid wire rope has wider contact areas with minimal breaks caused by inside abrasion. They boast low bending fatigue and higher breaking load without any destruction of strand shapes taking advantages of their tight structure. Normally, parallel laid wire ropes can be classified into four types: seale type (S), filler wire type (F), warrington type (W) and warrington & seale type (WS) as shown below:















Specification
item
value
Steel Grade
Carbon Steel 45# 60# 70#
Standard
AiSi, ASTM, DIN
Place of Origin
China

Hebei
Type
galvanized
Application
MANUFACTURING
Alloy Or Not
Non-Alloy
Special Use
Free Cutting Steel
Model Number
Galvanized
Brand Name
Qijie
Tolerance
±3%
Processing Service
Decoiling
Grade
70#
Wire Gauge
0.1mm-6.0mm
Material
Galvanized
Product name
High Strength Galvanized Steel Wire Rope
Wire Diameter
0.1mm-6.0mm
Usage
Making brush,springs,upholstered furniture,etc
Surface treatment
Galvanzied & copper coated
Zinc coating
20-260g/m2
Surface
Galvanised Zinc/ungalvanised
Tensile strength
1770mpa
Packing
Pallets



galvanized steel wire rope



galvanized steel wire rope



galvanized steel wire rope
