2inch Galvanized Welded Mesh Panel Construction Metal Reinforcing Sheet

Large Image : 2inch Galvanized Welded Mesh Panel Construction Metal Reinforcing Sheet

Product Details:

Place of Origin:	CHINA
Brand Name:	QIJIE
Certification:	SGS, ISO
Model Number:	QJ-WMP-01

Payment & Shipping Terms:

Minimum Order Quantity:	1000 square meters
Price:	USD 0.5-5/M2
Packaging Details:	pallets
Delivery Time:	10-15 working days
Payment Terms:	TT,LC,
Supply Ability:	1000 square meters per day

Contact Now

Detailed Product Description

Hole Shape:	Square,Rectangle,long Hole	Wire Gauge:	0.5mm-14mm,2.0-4.0mm,BWG#12--#26,0.3-2.5mm,0.3mm-8.0mm
Application:	Construction Wire Mesh,Fence Mesh,building,bridge,garden Fence	Type:	Welded Mesh,Electric Wire Mesh,Panel Or Roll
Aperture:	1/2",1/4"-6",1" X 2" Ect	Surface Treatment:	Hot Dipped Galvanized,pvc Coated,galvanized/pvc Coated,powder Coated
Width:	0.5-2m,0.5-1.8m,300mm-2500mm,0.5m To 2.2m,1.2m	Length:	30m,50m,10m,5m,25m
Usage:	Protection,building,construction	Packing:	Pallet,in Bulk
Product Name:	Welded Wire Mesh,Galvanized / PVC Coated Welded Wire Mesh	Color:	Silver,Green,Grey,etc
Name:	Welded Wire Mesh,Stone Cage Net,pvc Coated Reinforced Concrete Welded Wire Mesh For Sale	Hole Size:	5/8'' As Customer Request
Wire Diameter:	1.0mm~4.50mm	Mesh Size:	50x100mm
Email:	Devin@industrialmetalmesh.com	Whatsapp:	+8615369013183
Highlight:	2inch galvanized welded mesh panel , construction reinforcing galvanized welded mesh panel , 2inch welded steel wire panels

2inch Galvanized Construction Metal Reinforcing Welded Wire Mesh Sheet

Welded wire mesh, or welded wire fabric, or "weldmesh" is an electric fusion welded prefabricated joined grid consisting of a series of parallel longitudinal wires with accurate spacing welded to cross wires at the required spacing.
Machines used to produce the mesh must be with precise dimensional control. The product in considerable savings in time. labor and money.

Till now, we have 8 sets of large-scale automatic multiple spot welding machine, 7 stes of medium -sized multiple spot welding machine.
As for the production ability, we can produce 150-300 tons of welded wire mesh per month.(about 7-15 40' high containers)

As a leading welded wire mesh supplier and manufacturer,we offers a full range of welded wire mesh for various applications. We supply the mesh from 1/2" to 6", customer requst can be customized .Welded wire mesh is generally constructed in rolls or flat panels designed by customers. Green plastic coated is widely used for fence and breeding .Custom wire openings available upon request.

Electro galvanized welded wire mesh
This type of welded wire mesh is designed for building fencing and for other infrastruc- tural purposes. lt is a type of corrosion resis- tantwire mesh that mainly used in structural building. lt is also available in different forms like rolls and panelsfor industrial uses.

[ Specifications ]
welded wire mesh rolls
Opening Wire diameter Available Width
1/4" x 1/4" 0.45mm-0.7mm 300mm-1830mm
3/4" x 3/4" 0.7mm-2.0mm 300mm-1830mm
3/8" x 3/8" 0.7mm-1.1mm 300mm-1830mm
5/8" x 5/8" 0.8mm-1.2mm 300mm-1830mm
1/2" x 1/2" 0.45mm-1.6 mm 300mm-1830mm
1" x 1" 0.7mm-3.0mm 300mm-2000mm
1" x 1/2" 0.8mm-1.6mm 300mm-1828mm
1-1/2" x 1-1/2" 0.7mm-3.5mm 300mm-1828mm
1" x 2" 1.6mm-2.1mm 300mm-1828mm
2" x 2" 0.7mm-4.0mm 300mm-2500mm
2" x 3" 1.5mm-3.5mm 300mm-2000mm
2" x 4" 2.0mm-4.0mm 300mm-1828mm
3" x 3" 1.0mm-4.5mm 300mm-2500mm
3" x 4" 1.5mm-4.5mm 300mm-2000mm
4" x 4" 1.0mm-4.5mm 300mm-2500mm
5" x 5" 2.5mm-4.5mm 300mm-2500mm
6" x 6" 2.5mm-4.5mm 300mm-2500mm

Welded Wire Mesh Panels
Opening Wire diameter Available width
1/2" x 1/2" 0.45mm-2.0mm 100mm-1830mm
1" x 1" 0.7mm-3.5mm 100mm-2000mm
1" x1/4" 0.45mm-4.0mm 100mm-2000mm
1x 1/2" 0.45mm-4.0mm 100mm-3600mm
2" x 2" 0.7mm-6.0mm 100mm-3600mm
3" x 3" 1.0mm-7.0mm 100mm-3600mm
4" x 4" 1.0mm-8.0mm 100mm-3600mm
5" x 5" 2.5mm-9.0mm 100mm-3600mm
6" x 6" 2.5mm-10.0mm 100mm-3600mm

Roll or panel length can be negotiated, welcome to contact us for further information.
[ Quality Standard ]

Our products can meet below quality standard:
[ JG/T114-1997 ] National Standard
[ BS4483 ] British Standard
[ DIN488 ] German Standard
[ SIA16211 S550 ] Swiss Fabric Standard
[ NFA35-016 ] Franch Fabric Standard
[ onORM B4200/7 ] Australian Fabric Standard
