Product Details:
Payment & Shipping Terms:
|
| Material: | Mild Steel | Gauge: | 1.2mm |
|---|---|---|---|
| Barbe Distance: | 13cm | Weight Per Roll: | 20kg Per Coil |
| Length Per Roll: | 500m | Name: | 10kgs 15kgs 17kgs 20kgs Per Roll 9 Gauge Military Barbed Wire Pvc Coated |
| High Light: | 10 Gauge Galvanized Iron Barbed Wire,2.0mm Galvanized Iron Barbed Wire |
||
Cheap Used Military Plastic Galvanized Iron 2.0mm 10 Gauge For Sale Barbed Wire
Barbed wire is an isolation protective product which is cheap and easily installation. It is made by winding the barbed iron wire on the main wire (strand wire) through a barbed wire machine, and through a variety of weaving processes.
Barbed Wire Materials:
Material: high-quality low carbon steel wire, stainless steel wire, medium carbon steel wire(galvanized, plastic coated, plastic sprayed)
Assortment:
Electro-galvanized Barbed Wire,
Hot Dipped Barbed Wire and
PVC Barbed Wire
Barbed wire weave types:
1) single strand barbed wire,
2) double-strand reverse twisted barbed wire;
3) double-strand common twisted barbed wire
Common Gauge of Strand and Barb:
1.8X1.8mm / 2.0X2.0mm / 2.2X2.0mm / 2.2X2.2mm / 2.5X2.0mm / 2.5X2.2mm / 2.6X2.2mm / 2.7X2.2mm / 2.8X2.2mm /
3.0X2.0mm.
Barb Spacing: 3''-6'.
Barbed Wire Roll Length:200m/250m/400m/500m/600m.
Characteristic: firm and beautiful.
Barbed Wire Uses:
Barbed wire can be widely used as accessories for woven wires fences to form a fencing system or security system. barbed wire is suitable for industry, agriculture,
animal husbandry, dwelling house, plantation or fencing.
It is called barbed wire fences or barbed obstacles when it is used simply by itself along the wall or the building to give a kind of protection.
Advantages: Because of its convenient delivery, easy installment and unique modal, enable it can bring wonderful protective effects.
| Specification of Barbed Wire | ||||
| Gauge of Strand and Barb in BWG(Anne X3) |
Approximate Length per kilogram in Meter | |||
| Barbs Spacing 3'' | Barbs Spacing 4'' | Barbs Spacing 5'' | Barbs Spacing 6'' | |
| 12x12 | 6.0167 | 6.7590 | 7.2700 | 7.6376 |
| 12x14 | 7.3335 | 7.9051 | 8.3015 | 8.5741 |
| 12-1/2x12-1/2 | 6.9223 | 7.7190 | 8.3022 | 8.7221 |
| 12-1/2x14 | 8.1096 | 8.8140 | 9.2242 | 9.5620 |
| 13x13 | 7.9808 | 8.8990 | 9.5721 | 10.0553 |
| 13x14 | 8.8448 | 9.6899 | 10.2923 | 10.7146 |
| 13-1/2x14 | 9.6079 | 10.6134 | 11.4705 | 11.8553 |
| 14x14 | 10.4569 | 11.6590 | 12.5423 | 13.1752 |
| 14-1/2x14-1/2 | 11.9875 | 13.3671 | 14.3781 | 15.1034 |
| 15x15 | 13.8927 | 15.4942 | 16.6666 | 17.5070 |
| 15-1/2x15-1/2 | 15.3491 | 17.1144 | 18.4060 | 19.3386 |
| Wire gauge |
Weight 10kgs per coil |
Weight 15kgs per coil |
Weight 25kgs per coil |
|||
| 1X20FCL | Length | 1X20FCL | Length | 1X20FCL | Length | |
| 16#X16# | 15TONS | 160M | 15TONS | 240M | 16TONS | 400M |
| 16#X14# | 16TONS | 125M | 16TONS | 180M | 17TONS | 300M |
| 14#X14# | 17TONS | 100M | 17TONS | 150M | 18TONS | 250M |
| 14#X12# | 18TONS | 80M | 18TONS | 120M | 19TONS | 200M |
| 12#X12# | 19TONS | 65M | 19TONS | 100M | 20TONS | 160M |
The others can make according to custmoers request.
Main Features.
1) Sharp edge frightens intruders and thieves.
2) High stability, rigidity, and tensile strength to prevent cutting or destroying.
3) Anti-acid and alkali.
4) Harsh environment resistance.
5) Corrosion and rust resistance.
6) Available to combine with other fences for high level security barrier.
7) Convenient installation and uninstallation.
8) Easy to maintain.
9) Durable and long service life.
Application:
Barbed wire is mainly used in protecting of grass boundary,railway,highway,nation defence,airport,orchard,etc. It has a excellent protective performance,beautiful appearance, various patterns.
