2.0mm 3.0mm 4.0mm Hot DIP Galvanized Welded Wire Mesh Panel
Black Steel Bar Welded Wire Mesh is a pre-fabricated steel bar mesh used for concrete reinforcing in various construction projects. We supply high-grade steel bar welded grid/mat black finish or galvanized for additional corrosion protection.
1. Wire diameter: Ribbed steel bar ranging from 3mm to 8mm in diameter.
2. Opening: 4" x 4" is a common size, smaller and larger sizes are also available.
3. Finishes: The mesh can be black steel bar mesh, and galvanizing can be added.
4. Materials: Low-carbon steel or mild steel.
MAIN PRODUCTS
RIBBED STEEL BAR WELDED MESH, 100X100MM
Bar material: Ribbed Steel Bar A400 NR from diameter 6mm to 32mm
Ribbed Steel Bar A400 NR Welded Mesh Panel 2300x5800mm
Mesh sizes: 100x100mm
Steel Bar: 8mm
Hole shape: Square
STEEL BAR WELDED WIRE MESH, 1.5MX5.8M PANEL
Black wire, None galvanized
Mesh size: 100mm/200mm
Wire diameter: 5.8mm
Panel size : 1.5mx5.8m
RIBBED STEEL BAR WELDED MESH PANEL, 100X200MM
Mesh size: 100x200mm
Steel Bar: 8mm
Hole shape: Rectangular
Ribbed Steel Bar A400 NR
RIBBED STEEL BAR WELDED MESH, 200X200MM
Mesh size: 200x200mm
Steel Bar 8mm
Hole shape: Square
Ribbed Steel Bar A400 NR Welded Mesh Panel 2300x5800mm
RIBBED BAR WELDED SQUARE MESH
Mesh size: 3000x2400, D8, space 100
Min 500Mpa Yield Strength
WELDED DEFORMED BAR MESH SHEET
Wire: 6mm diameter deformed bar
Mesh size 150mmx150mm
Sheet sizes 1.2x2.4 meter/4x8ft
| Welded wire mesh specification ( Standard length: 30m / roll , Width : 0.3m - 2.5m ) |
| Opening in inch |
Wire diameter (bwg) |
| 1/4 '' x 1/4 '' |
22 , 23, 24 |
| 3/8 '' x 3/8 '' |
19 , 20 , 21 , 22 |
| 1/2 '' x 1/2 '' |
16 , 17 , 18 , 19 ,20 , 21 , 22 , 23 |
| 5/8 '' x 5/8 '' |
18 , 19 , 20 , 21 |
| 3/4 '' x 3/4 '' |
16 , 17 , 18 , 19 , 20 , 21 |
| 1 '' x 1 '' |
16 , 17 , 18 , 19 |
| 1 '' x 1/2 '' |
16 , 17 , 18 , 19 , 20 , 21 |
| 1 '' x 1/4 '' |
14 , 15 , 16 , 18 |
| 1 '' x 2 '' |
14 , 15 , 16 |
| 2'' x 2 '' |
7, 8, 9 , 10 , 11,12 |
| 4'' x 4'' |
7, 8, 9 , 10 , 11,12 |
| 6'' x 6'' |
7, 8, 9 , 10 , 11,12 |
| Wire Diameter |
Mesh |
Width |
| inch |
mm |
| 2.0mm ~ 3.2mm |
1" |
25.40 |
0.914m ~ 1.83m |
| 2.0mm ~ 4.5mm |
2" |
50.80 |
0.914m ~ 2.75m |
| 2.0mm ~ 6.0mm |
3" |
70.20 |
0.914m ~ 2.75m |
| 2.0mm ~ 6.0mm |
4" |
101.6 |
0.914m ~ 2.75m |
| 2.0mm ~ 6.0mm |
5" |
127.0 |
0.914m ~ 2.75m |
| 2.0mm ~ 6.0mm |
6" |
152.4 |
0.914m ~ 2.75m |
| 2.0mm ~ 6.0mm |
7" |
177.8 |
0.914m ~ 2.75m |
| 2.0mm ~ 6.0mm |
8" |
203.2 |
0.914m ~ 2.75m |
Product Characters of welded wire mesh :
1 . Excellent heat resistant and high intensity .
2 . High strength and strong integration .
3 . Flat and smooth surface combined with firm structure .
4 . Perfect Anti - Rust Property .
5 . Stay Holistiv even cut into fragmented parts .
6 . Long Using Life
7 . Hot dipped galvanized after welded. Not black welded point, more zinc coated ensure it has better anti-rust and last longer. But it also lead to higher cost.
Surface Treatment:
Hot dipped galvanizing after weaving
Weaving with hot dipped galvanized iron wire
Electric galvanizing after weaving
Weaving with electric galvanized iron wire
PVC coated welded wire mesh
Product Characters of welded wire mesh :
1 . Excellent heat resistant and high intensity .
2 . High strength and strong integration .
3 . Flat and smooth surface combined with firm structure .
4 . Perfect Anti - Rust Property .
5 . Stay Holistiv even cut into fragmented parts .
6 . Long Using Life
7 . Hot dipped galvanized after welded. Not black welded point, more zinc coated ensure it has better anti-rust and last longer. But it also lead to higher cost.
