Affordable 500mm Length Q345B HDG Dowel Steel Bars For Various Applications

Affordable 500mm Length Q345B HDG Dowel Steel Bars For Various Applications
Affordable 500mm Length Q345B HDG Dowel Steel Bars For Various Applications

Large Image :  Affordable 500mm Length Q345B HDG Dowel Steel Bars For Various Applications

Product Details:
Place of Origin: China
Brand Name: Qijie
Certification: Dowel bar
Model Number: Dowel bar
Payment & Shipping Terms:
Minimum Order Quantity: 100pcs
Packaging Details: paper carton
Delivery Time: 7-10days
Payment Terms: L/C, T/T, Western Union, MoneyGram
Supply Ability: 1tons/day
Contact Now
Detailed Product Description
Material: Q345b Diameter: 25mm
Length: 500mm
Highlight:

Q345B Dowel Steel Bars

,

500mm Length Dowel Steel Bars

,

HDG Dowel Steel Bars

HDG Dowel Steel Bars with Cheap Prices​



Hot dipped galvanised steel dowel pins are friction cut to length, not cropped. They are available in a variety of standard, off-the-shelf sizes. Round dowels are manufactured from AS/NZS 3679.1 compliant Grade 300 steel, and are hot-dipped galvanised to AS/NZS 4680.

Features:

  • Available in 12mm,16mm, 20mm, 24mm 30mm, 32mm,60mm diameter standard dowel sizes.
  • Available in 5 standard lengths:

300mm length: 12mm
400mm length: 16mm & 20mm
450mm length: 24mm & 33mm
500mm length: 16mm & 20mm
600mm length: 16mm & 20mm

  • Dowels manufactured from AS/NZS 3679.1, Grade 300 steel.
  • Hot dipped galvanised to AS/NZS 4680 as standard.
  • Fiction cut dowels, not cropped.
  • Custom lengths available upon request. Minimum order quantites will apply.

Affordable 500mm Length Q345B HDG Dowel Steel Bars For Various Applications 0

Steel Dowel Bars Specification :

Standard : ASTM A615, ASTM A1078, ASTM A775, BS4449, AASHTO M254

Epoxy Coating Standard : ASTM A775 / A775M

Ends : Chamfering & Plain

Grade : ASTM A615 Grade 60, Grade 250

Length : 100mm to 6000mm



Mild Carbon Steel Dowel Bar
Product Coating Steel Grade Coated Standard Diameter (mm) Diameter (inches)
Dowel Bar Black(uncoated) BS4449-grade250, ASTM A615/A615M, A615 Gr60, Gr40, Grade500N, Q235B, SS400, S275JR, etc AISI, ASTM, BS, DIN, GB, JIS 16 ~ 50 5/8″~ 2″
Epoxy coated dowel bar Epoxy coated ASTM A1078 16 ~ 50 5/8“~ 2“
Galvanized dowel bar Galvanized BS EN ISO 1461:2009; AS/NZS 4680 16 ~ 50 5/8“~ 2“



Affordable 500mm Length Q345B HDG Dowel Steel Bars For Various Applications 1



Affordable 500mm Length Q345B HDG Dowel Steel Bars For Various Applications 2
