Steel Construction Materials HDG Round Dowels Bar 500mm Length Q345B

Large Image : Steel Construction Materials HDG Round Dowels Bar 500mm Length Q345B

Product Details:

Place of Origin:	China
Brand Name:	Qijie
Certification:	Dowel bar
Model Number:	Dowel bar

Payment & Shipping Terms:

Minimum Order Quantity:	100pcs
Packaging Details:	paper carton
Delivery Time:	7-10days
Payment Terms:	L/C, T/T, Western Union, MoneyGram
Supply Ability:	1tons/day

Contact Now

Detailed Product Description

Material:	Q345b	Diameter:	25mm
Length:	500mm	Email:	Devin@industrialmetalmesh.com
Whatsapp:	+8615369013183
Highlight:	500mm Round Dowels Bar , Q345B Round Dowels Bar , HDG Round Dowels Bar

Steel Construction Materials HDG Round Dowels Bar

Product Description

Steel construction materials HDG round dowels bar
Description
Structural grade round dowels are friction cut to length, not cropped. They are available in a variety of standard, off-the-shelf sizes.
Round dowels are manufactured from AS/NZS 3679.1 compliant Grade 300 steel, and are hot-dipped galvanised to AS/NZS 4680.

Features:

Dowels manufactured from AS/NZS 3679.1, Grade 300 steel.
Hot dipped galvanised to AS/NZS 4680 as standard.
Fiction cut dowels, not cropped.
Custom lengths available upon request. Minimum order quantites will apply.

Specification:

Hot-dip galvanised Dowels:
Product	Shape	Diameter / Size	Length	Recommended Sleeve
Product	Shape	[mm]	[mm]	Recommended Sleeve
DBHDG12Rx300mm	Round	12	300	EXJDS12Rx150
DBHDG16Rx450mm	Round	16	450	UDS16Rx230
DBHDG16Rx600mm	Round	16	600	UDS16Rx300
DBHDG20Rx450mm	Round	20	450	UDS20Rx230
DBHDG20Rx600mm	Round	20	600	UDS20Rx300
DBHDG24Rx450mm	Round	24	450	UDS24Rx225
DBHDG33Rx450mm	Round	33	450	UDS33Rx230
DBHDG33Rx600mm	Round	33	600	UDS33Rx300
DBHDG36Rx450mm	Round	36	450	UDS36Rx230
DBHDG36Rx600mm	Round	36	600	UDS36Rx300
DBHDG16SQx450mm	Square	16 x 16	450	UDS16Sx230
DBHDG16SQx600mm	Square	16 x 16	600	UDS16Sx300
DBHDG20SQx450mm	Square	20 x 20	450	UDS20Sx230
DBHDG20SQx600mm	Square	20 x 20	600	UDS20Sx300

Mill finished Dowels:
Product	Shape	Diameter / Size	Length	Recommended Sleeve
Product	Shape	[mm]	[mm]	Recommended Sleeve
DB12Rx300mm	Round	12	300	EXJDS12Rx150
DB16Rx450mm	Round	16	450	UDS16Rx230
DB16Rx600mm	Round	16	600	UDS16Rx300
DB20Rx450mm	Round	20	450	UDS20Rx230
DB20Rx600mm	Round	20	600	UDS20Rx300
DB24Rx450mm	Round	24	450	UDS24Rx225
DB33Rx450mm	Round	33	450	UDS33Rx230
DB33Rx600mm	Round	33	600	UDS33Rx300
DB36Rx450mm	Round	36	450	UDS36Rx230
DB36Rx600mm	Round	36	600	UDS36Rx300
DB16SQx450mm	Square	16 x 16	450	UDS16Sx230
DB16SQx600mm	Square	16 x 16	600	UDS16Sx300
DB20SQx450mm	Square	20 x 20	450	UDS20Sx230
DB20SQx600mm	Square	20 x 20	600	UDS20Sx300

Steel Construction Materials HDG Round Dowels Bar 500mm Length Q345B 0

Steel Dowel Bars Specification :

Standard : ASTM A615, ASTM A1078, ASTM A775, BS4449, AASHTO M254

Epoxy Coating Standard : ASTM A775 / A775M

Ends : Chamfering & Plain

Grade : ASTM A615 Grade 60, Grade 250

Length : 100mm to 6000mm

Mild Carbon Steel Dowel Bar
Product	Coating	Steel Grade	Coated Standard	Diameter (mm)	Diameter (inches)
Dowel Bar	Black(uncoated)	BS4449-grade250, ASTM A615/A615M, A615 Gr60, Gr40, Grade500N, Q235B, SS400, S275JR, etc	AISI, ASTM, BS, DIN, GB, JIS	16 ~ 50	5/8″~ 2″
Epoxy coated dowel bar	Epoxy coated		ASTM A1078	16 ~ 50	5/8“~ 2“
Galvanized dowel bar	Galvanized		BS EN ISO 1461:2009; AS/NZS 4680	16 ~ 50	5/8“~ 2“

Steel Construction Materials HDG Round Dowels Bar 500mm Length Q345B 1

Steel Construction Materials HDG Round Dowels Bar 500mm Length Q345B 2
