Electromagnetic Shielding & Electromagnetic Radiation Protection Copper Mesh

Large Image : Electromagnetic Shielding & Electromagnetic Radiation Protection Copper Mesh

Product Details:

Place of Origin:	China
Brand Name:	Qijie
Certification:	Copper Mesh
Model Number:	copper shielding mesh

Payment & Shipping Terms:

Minimum Order Quantity:	100pcs
Price:	Discuss
Packaging Details:	paper cartons
Delivery Time:	15-18days
Payment Terms:	L/C, T/T
Supply Ability:	1500pcs

Contact Now

Detailed Product Description

Highlight:

electromagnetic shielding copper mesh

radiation protection metal wire mesh

copper mesh for emf shielding

Electromagnetic Shielding & Electromagnetic Radiation Protection Copper Mesh

Copper wire meshes from Boegger are used in hospitals, machine rooms, labs, optical components and systems to provide shielding from electromagnetic interference and radio frequency interference.

Before you send us the inquiry, please tell the request shielding performance, (like our another customer request a shielding performances around 60 dB at 6 Ghz). Then we can recommend you the suitable mesh count. Besides, you can use the copper mesh shielding effectiveness calculator to determine if the copper mesh can satisfy your requirements.

Electromagnetic Shielding & Electromagnetic Radiation Protection Copper Mesh 0

Functions

Electromagnetic radiation protection, effectively blocks the damage of electromagnetic waves to the human body.
Shield electromagnetic interference to ensure the normal operation of the equipment.
Prevent electromagnetic leakage and effectively shield the electromagnetic signal of the display window.

Specifications

Avaiable Sizes
Item	Mesh/Inch	Diameter		Opening		Weight
		mm	inch	mm	inch	kg/m2
CSM-1	50*	0.18	0.007	0.33	0.013	0.87
CSM-2	60	0.16	0.006	0.26	0.01	0.83
CSM-3	60	0.19	0.007	0.23	0.009	1.17
CSM-4	70	0.12	0.005	0.24	0.01	0.54
CSM-5	80	0.12	0.005	0.2	0.008	0.62
CSM-6	80	0.13	0.005	0.19	0.007	0.73
CSM-7	100*	0.1	0.004	0.15	0.006	0.54
CSM-8	100	0.11	0.004	0.14	0.006	0.65
CSM-9	104	0.06	0.002	0.18	0.007	0.20
CSM-10	120*	0.09	0.004	0.12	0.005	0.52
CSM-11	120*	0.058	0.002	0.15	0.006	0.22
CSM-12	120*	0.08	0.003	0.13	0.005	0.41
CSM-13	140	0.07	0.003	0.11	0.004	0.37
CSM-14	145	0.045	0.002	0.13	0.005	0.16
CSM-15	150*	0.06	0.002	0.11	0.004	0.29
CSM-16	150*	0.05	0.002	0.12	0.005	0.20
CSM-17	160	0.05	0.002	0.11	0.004	0.22
CSM-18	160	0.04	0.002	0.12	0.005	0.14
CSM-19	160	0.035	0.001	0.12	0.005	0.11
CSM-20	165	0.05	0.002	0.1	0.004	0.22
CSM-21	180	0.05	0.002	0.09	0.004	0.24
CSM-22	180	0.04	0.002	0.1	0.004	0.16
CSM-23	200*	0.053	0.002	0.07	0.003	0.30
CSM-24	200*	0.05	0.002	0.08	0.003	0.27
CSM-25	200*	0.04	0.002	0.09	0.003	0.17

Applications

Electromagnetic shielding or electromagnetic radiation protection while light transmission is required, like shielding the instrument display window.
Electromagnetic shielding or electromagnetic radiation protection while ventilation is required, such as chassis, cabinet, ventilation window, etc.
Electromagnetic shielding or electromagnetic wave radiation on walls, floors, ceilings, etc.; such as laboratory, computer room, strong electric weak room, radar station, etc.
Anti-electromagnetic interference for wire and cable.

Application scenario 1: Hospital

For the (MRI) machines in the scan room, which can prevent external RF (radio frequency) signals from affecting patient scan imaging.

Electromagnetic Shielding & Electromagnetic Radiation Protection Copper Mesh 1

Application scenario 2: Faraday cage room (data center)

Avoid the electromagnetic interference using malware to destroy data.

Electromagnetic Shielding & Electromagnetic Radiation Protection Copper Mesh 2
