304L Pickling Bright Polished Electro 2mm 3mm 4mm Stainless Steel Wire

Large Image : 304L Pickling Bright Polished Electro 2mm 3mm 4mm Stainless Steel Wire

Product Details:

Place of Origin:	Hebei, China
Brand Name:	QIJIE
Certification:	CE,SGS,ISO
Model Number:	SW-004

Payment & Shipping Terms:

Minimum Order Quantity:	100kg
Packaging Details:	wooden case
Delivery Time:	10-15 working days
Payment Terms:	30%TT in advance, Balance before loading
Supply Ability:	30000 kg/month

Contact Now

Detailed Product Description

Material:

Stainless Steel Wire

Wire Diameter:

0.17mm

Highlight:

304L stainless steel wire

pickling bright polished steel wire

electro galvanized binding wire

304L Pickling Bright Polished Electro 2mm 3mm 4mm Stainless Steel Wire

Product	Steel Wire Rod
Standard	AISI, ASTM, BS, DIN, GB, JIS
Certifications	ISO 9001 BV SGS
Material	201, 202, 301, 302, 304, 304L, 310S, 316, 316L, 321, 430, 430A, 309S, 2205, 2507, 2520, 430 , 410, 440, 904Lect, Or Customized
Material:	HRB355 HRB400 HRB500 Q195 - 235; SAE1008 - SAE1018
Surface Treatment	1. Galvanized
	2. PVC, Black and color painting
	3. Transparent oil, anti-rust oil
	4. According to the client's requirement
Diameter(Hot rolled):	5.5mm,6.5mm,8.0mm,10mm,12mm,14mm,16mm,20mm,22mm,24mm
Diameter(Cold rolled):	0.8mm-5.5mm
Packing	Iron sheet in both ends,All wrapped packing with plastic woven bag,Loose package,As the requirement of customer.
Application	Construction/Shipbuilding/Machinery manufacturing/Steel structure
Surface	Bright/ Matt
MOQ	10 Tons
Payment terms	L/C T/T (30%DEPOSIT)
Stock or not	enough stock
Sample	Provided Freely
Container Size	20ft GP: 5898mm(Length)x2352mm(Width)x2393mm(High)
	40ft GP: 12032mm(Length)x2352mm(Width)x2393mm(High)
	40ft HC: 12032mm(Lengh)x2352mm(Width)x2698mm(High)
Delivery time	Fast delievery in 7 days,up to order quantity

Product Name	Stainless steel wire
Type	200 series: 201,202
	300 series: 301,302,304,304L,308,309S,310s,316,316L,321,347
	400 series: 410,420,430,434
Wire diameter	0.02-5mm
Standard	ASTM AISI GB JIS SUS DIN
Length	As customers' requirement
Package	Spool or roll
Usage	Lifting,fixing,cableway,hanging,supporting,refloatation,haulage.

Gauge	SWG		BWG		AWG
Gauge	Inch	mm	Inch	mm	Inch	mm
8	0.16	4.046	0.165	4.191	0.1285	3.264
9	0.144	3.658	0.148	3.759	0.1144	2.906
10	0.128	3.215	0.134	3.404	0.1019	2.588
11	0.116	2.946	0.12	3.048	0.0907	2.305
12	0.104	2.642	0.109	2.769	0.0808	2.053
13	0.092	2.337	0.095	2.413	0.072	1.828
14	0.08	2.032	0.083	2.108	0.0641	1.628
15	0.072	1.829	0.072	1.829	0.0571	1.45
16	0.064	1.626	0.065	1.651	0.0508	1.291
17	0.056	1.422	0.058	1.473	0.0453	1.15
18	0.048	1.219	0.049	1.245	0.0403	1.024
19	0.04	1.016	0.042	1.067	0.0359	0.912
20	0.036	0.914	0.035	0.839	0.032	0.812
21	0.032	0.813	0.032	0.831	0.0285	0.723
22	0.028	0.711	0.028	0.711	0.02535	0.644
23	0.024	0.61	0.025	0.635	0.02256	0.573
24	0.022	0.559	0.022	0.559	0.02011	0.511
25	0.02	0.508	0.02	0.508	0.01791	0.455
26	0.018	0.457	0.018	0.457	0.01594	0.405

Use: Stainless steel microfilaments are widely used in textile, aerospace, pharmaceutical, biochemical, modern industrial, modern civil, petrochemical and other industries. Due to the high scientific and technological content of stainless steel microfilaments, and has a broad market prospects. Widely used in stainless steel wire mesh weaving, stainless steel wire rope, stainless steel hose, stainless steel binding wire, Sewing thread, etc.

Feature
1.Good electric and thermal conduction.
2. Anti-static, radiation protection, long life etc.
3. Excellent heat resistance, ease of fabrication, most importantly the cleanability and hygiene properties.
4. Good acid and alkali resistance, corrosion resistance.
5. High strength, high tensile strength, wear resistance and durability.
6. Strong oxidation resistance, strong solder joint, bright surface.
7. Don't need special surface treatment, it is easy to maintain.

304L Pickling Bright Polished Electro 2mm 3mm 4mm Stainless Steel Wire 0

The feature of Stainless Steel Spring Wire

1.Corrosion Resistance

Stainless steel spring wire has excellent corrosion resistance, which is one of its most significant properties. Due to the presence of chromium in stainless steel, a dense oxide film can be formed on the surface of the material, effectively preventing corrosion from corrosive media such as oxygen and moisture. Therefore, stainless steel spring wires can still maintain good performance in harsh environments such as humidity, acidity, and alkalinity, greatly extending their service life.

2.High Strength

Stainless steel spring wire has the characteristic of high strength and can withstand large tensile and compressive forces. This gives it significant advantages in manufacturing parts such as springs that require high strength loads. At the same time, the high strength of stainless steel spring wire also ensures that it is not easily deformed or broken during use, improving the safety and reliability of the product.

3.Good Elasticity

Elasticity is one of the important performance indicators of spring wire materials. Stainless steel spring wire has good elasticity and can quickly return to its original state after being subjected to external forces. This feature makes stainless steel spring wire have a wide range of application prospects in manufacturing various elastic components, such as automotive shock absorbers, springs in household appliances, etc.
