16 Gauge 1 X 1/2 Inch Galvanized Welded Wire Mesh Roll for Raising Animals

Large Image : 16 Gauge 1 X 1/2 Inch Galvanized Welded Wire Mesh Roll for Raising Animals

Product Details:

Place of Origin:	CHINA
Brand Name:	QiJie
Certification:	ISO9001:2008, SGS, CE
Model Number:	01WWM

Payment & Shipping Terms:

Minimum Order Quantity:	50 rolls
Price:	USD9.90-USD45.90
Packaging Details:	Plastic film or water proof paper
Delivery Time:	10-25days
Payment Terms:	TT,LC,
Supply Ability:	1000 rolls/per day

Contact Now

Detailed Product Description

Material:	Carbon Steel Wire	Mesh Opening:	12 × 12, 20 × 20, 25 × 25, 12 × 25mm
Wire Diameter:	0.4mm - 1.5mm	Roll Width:	0.4m,0.5m,0.6m,0.8m, 1.0m, 1.25m, 1.5m, 2.0m
Roll Length:	15M,30M,50M Ect	Surface Treatment:	Hot Dipped Galvanized Or Electric Galvanized
Model Number:	Xx-01001	Application::	Fence Mesh
Email:	Devin@industrialmetalmesh.com	Whatsapp:	+8615369013183
Highlight:	16 gauge welded wire mesh roll , galvanized welded wire mesh fencing , animal enclosure welded wire mesh

16 Gauge 1 X 1/2 Inch Galvanized Welded Wire Mesh Roll for Raising Animals

Product Description:

Welded wire mesh is also known as exterior wall insulation wire mesh, galvanized wire mesh, galvanized welded wire mesh, steel wire mesh, spot welded mesh, construction mesh, exterior wall insulation mesh, decorative mesh, wire mesh, square mesh, screen mesh, and anti-crack mesh.

Stainless steel welded wire mesh is made by spot welding high-quality stainless steel wires. It features acid and alkali resistance, firm welding, good appearance and wide application.

Packaging: The general packaging of welded wire mesh is moisture-proof paper (the color is mostly grayish white or yellow, with trademarks, certificates of conformity, etc.). Some are small wire diameter welded wire mesh with a diameter of 0.3-0.6mm for domestic sales. Due to the fine and soft wire and the fact that it is in small rolls, customers often require it to be bundled and bagged to prevent scratches and other damage caused by transportation.

The mesh wires of welded wire mesh can be straight or wavy (also known as Dutch mesh). According to the shape of the mesh surface, it can be divided into: welded wire mesh sheet and welded wire mesh coil.

16 Gauge 1 X 1/2 Inch Galvanized Welded Wire Mesh Roll for Raising Animals 0

Applications:

Plaster mesh is widely used as a reinforcing material to protect the internal and external walls,floors and ceilings against cracking in the industrial plants and other architectures.Plaster Welded Wire Mesh has a wide scope. It can be used for the building inside and outside plaster reinforcement. As an essential piece of plastering work, it creates lasting plaster coating for absolutely all surfaces of concrete and brick to wood, and even plaster ceilings. Before plastering, the welded mesh must be mounted on wall by a solid dowel-nails or anchor bolts, which makes the plaster work easier. The Plaster Welded Wire Mesh makes the plaster wall surface smooth and no crack, also excludes the impact of external factors on the wall.

Product Parameters

Specification of Welded Wire Mesh
Hole Size		Wire Diameter	Wide	Electric galvanized before welded, Electric galvanized after welded, Hot dipped galvanized before welded, Hot dipped galvanized after welded, PVC coated, Stainless steel wire (SUS304,SUS316,SUS316L);
In inch	In metric unit	Wire Diameter	Wide
1/4''X1/4''	6.4mmX6.4mm	BWG24-22	0.3-2.5m
1/4''X1/2''	6.4mmX12.7mm	BWG24-22	0.3-2.5m
1/4''X1''	6.4mmX25.4mm	BWG24-22	0.3-2.5m
1/3''X1/3''	8.5mmX8.5mm	BWG24-18	0.3-2.5m
3/8''X3/8''	9.5mmX9.5mm	BWG22-19	0.3-2.5m
1/2''X1/2''	12.7mmX12.7mm	BWG23-16	0.3-2.5m
3/4''X3/4''	19.1mmX19.1mm	BWG21-16	0.3-2.5m
1/2''X1''	12.7mmX25.4mm	BWG21-16	0.3-2.5m
1-1/2''X1-1/2''	38mmX38mm	BWG19-14	0.3-2.5m
1''X1''	25.4mmX25.4mm	BWG19-14	0.3-2.5m
2''X2''	50.8mmX50.8mm	BWG15-12	0.3-2.5m
4''X4''	101.6mmX101.6mm	BWG15-12	0.3-2.5m
Note: Special specification can be made according to customer's requires.

16 Gauge 1 X 1/2 Inch Galvanized Welded Wire Mesh Roll for Raising Animals 1

16 Gauge 1 X 1/2 Inch Galvanized Welded Wire Mesh Roll for Raising Animals 3

Specification
Opening		Wire Diameter	Width 0.4-2m Length 5-50m	electric galvanized before welded, electric galvanized after welded, hot-dipped galvanized before welded, hot-dipped galvanized after welded, PVC coated, Stainless steel wire
Inch	Metric Unit	Wire Diameter
1/4"x1/4"	6.4mmx6.4mm	BWG24-22
3/8"x3/8"	10.6mmx10.6mm	BWG22-19
1/2"x1/2"	12.7mmx12.7mm	BWG23-16
5/8"x5/8"	16mmx16mm	BWG21-18
3/4"x3/4"	19.1mmx19.1mm	BWG21-16
1"x1/2"	25.4mmx25.4mm	BWG21-16
1-1/2"x1 1/2"	38mmx38mm	BWG19-14
1"x2"	25.4mmx12.7mm	BWG16-14
2"x2"	50.8mmx50.8mm	BWG15-12
2"x4"	101.6mmx101.6mm	BWG15-12
4"x4"	101.6mmx152.4mm	BWG15-12
4"x6"	101.6mmx152.4mm	BWG15-12
6"x6"	152.4mmx152.4mm	BWG15-12
6"x8"	15.4mmx203.2mm	BWG14-12
Note:Special specification can be made according to customers requires

SURFACE TREATMENT

1.Electrical zinc coating mesh

First welding,cutting the edge of the panel which can make sure the edges is smooth and not hurt your hands,clectrical zinc coating,packing

2.Pre Galvanized mesh

Use the hot dip gal. wire direct do the welding,cutting the edge of the panel which can make sure the edge is smooth and not hurt your hands,packing

3.Hot dip galvanized mesh

First welding,cutting the edge of the panel which can make sure the edges is smooth and not hurt your hands,clectrical zinc coating,packing

4.PVC coated welded wire mesh
Black wire + PVC coated
Galvanized wire+PVC coated

16 Gauge 1 X 1/2 Inch Galvanized Welded Wire Mesh Roll for Raising Animals 5

16 Gauge 1 X 1/2 Inch Galvanized Welded Wire Mesh Roll for Raising Animals 6

Feature of plastering welded wire mesh:

1. economic and good looking

2. anti-corrosion and long service life

3. wide scope of using

16 Gauge 1 X 1/2 Inch Galvanized Welded Wire Mesh Roll for Raising Animals 7

Welded Wire Mesh Welding style:

Hot dipped galvanized after or before welding

Electro galvanized after or before welding

Weaving and characteristics:

Hot dipped galvanizing after welding

Welding with hot dipped galvanized iron wire

Electric galvanizing after welding

Welding with electric galvanized iron wire

PVC coated welded wire mesh

16 Gauge 1 X 1/2 Inch Galvanized Welded Wire Mesh Roll for Raising Animals 8

16 Gauge 1 X 1/2 Inch Galvanized Welded Wire Mesh Roll for Raising Animals 10

Qijie Wire Mesh MFG Co.,ltd is a professional manufacturer of fences, wire mesh products with more than 20 years experience. Welcome to visit our factory located in Anping city at any time!
