Ss 304 Stainless Steel Wire Mesh Projector Screen/Insect Nets/Security Screen for Windows

Large Image : Ss 304 Stainless Steel Wire Mesh Projector Screen/Insect Nets/Security Screen for Windows

Product Details:

Place of Origin:	Hebei, China
Brand Name:	XMESH
Certification:	SGS
Model Number:	18 x 14 mesh

Payment & Shipping Terms:

Minimum Order Quantity:	200pcs
Packaging Details:	wood case, palelts
Delivery Time:	15-25days
Payment Terms:	TT/LC
Supply Ability:	1000meters per week

Contact Now

Detailed Product Description

Mesh:	18 X 14 Mesh	Surface Treatment:	Nature Color
Material:	SUS304	Color:	Nature
Products Name:	Stainless Steel Insect Screen	Width:	6ft
Length:	30meters	Use:	Window Insect Screen
Email:	Devin@industrialmetalmesh.com	Whatsapp:	+8615369013183
Highlight:	Stainless Steel Wire Mesh Screen , 304 SS Insect Net , Security Window Mesh Screen

Ss 304 Stainless Steel Wire Mesh Projector Screen/Insect Nets/Security Screen for Windows

Stainless steel window security screens prevent doors and windows from being destroyed and unauthorized access. It is often used in residential and commercial environments. . Stainless steel security window screens represent excellent performance in high-strength, anti-corrosion and aesthetic appealing, which can meet the various needs of home and business environments.

Whether it is to prevent intrusion of strangers, vandals caused by the external environment and the severe natural weather such as hurricanes, or from an aesthetic perspective, stainless steel window security screens are ideal choice providing an added security guarantee to your home and business environment.

We offer various types of security window screens which is strong and versatile, and is very suitable for installation on doors and windows as security mesh.

If you are seeking for stainless steel window security screens, please get in touch with us, and we can customize suitable products according to your needs.

Product name	Insect Screen
Material	aluminum,stainless steel,fiberglass,plastic ect.
Color	Black, Grey, white gray, white, green, brown, ivory, etc
Mesh	1816, 1817, 1818, 1814,1414, 2020, etc
Width	0.6m to 3.0m, Customized
Application	Anti Mosquitoes, anti insect
Break strength	Warp direction>280N, Weft direction>240N

Ss 304 Stainless Steel Wire Mesh Projector Screen/Insect Nets/Security Screen for Windows 0

stainless steel window screen-001

Ss 304 Stainless Steel Wire Mesh Projector Screen/Insect Nets/Security Screen for Windows 1

stainless steel window screen-002

Material Of stainless steel insect screen:
stainless steel 304 ,316,316L mesh, carbon steel mesh
Aperture: 11x11mesh, 12x12 mesh, 14x14mesh,etc. .
Wire diameter: 0.7mm,0.80mm, 0.90mm, etc.

Characteristics of stainless steel insect screen:
Stainless steel insect screen has nice properties, such as good stablity, rust-resistance, heat-resistance, acid-resistance and corrosion-resistance and so on.
With those unique features, stainless steel window screening could be applied under high temperature workshops and civil constructions.
Various of Colors:
The color of stainless steel window screening could be white, green, black,etc. which could be ordered according to cunstomers' requirements.

Material	Mesh per inch	Wire Dia (mm)	Wire Dia (inch)	Open Area
AISI 316 or 304	10 x 10	0.9mm	0.035"	41.7
AISI 316 or 304	10 x 10	1.2mm	0.028"	27.8
AISI 316 or 304	10 x 10	0.8mm	0.032"	46.9
AISI 316 or 304	10 x 10	1.15mm	0.045"	29.9
AISI 316 or 304	11 x 11	0.8mm	0.032"	42.5
AISI 316 or 304	11 x 11	0.7mm	0.027"	48.3
AISI 316 or 304	12 x 12	0.7mm	0.027"	44.8
AISI 316 or 304	12 x 12	0.58mm	0.023"	52.8
Special mesh can be made according to customers requirement

Features

• Durability: Resistant to wear, tear, and foot traffic, easy to clean. Lifespan: 10-15 years
• Corrosion resistance: 201 and 304 materials: Suitable for general indoor/outdoor environments; 316 material: Exceptional salt spray resistance, ideal for coastal humid areas and high-corrosion environments.
• Safety and Environmental Protection: Food-grade Stainless Steel Material
• Powerful insect and theft prevention
• High transparency and wear resistance: Excellent light transmittance and breathability, smooth surface, high hardness, and scratch resistance.
• Fireproof and flame-retardant: does not burn upon exposure to open flame and does not produce toxic smoke.

Application:

· Civil buildings such as residences, hotels, and office buildings.
· Livestock farms, food processing plants, warehouses, and other high-protection requirement facilities.
· Agricultural and horticultural facilities such as greenhouses, tunnels, and nurseries.
· Commercial premises like restaurant terraces, bar patios, and mall ventilation openings.
· Industrial environments with cleanliness requirements, such as laboratories, clean rooms, and electronic workshops.
· Locations with dual high demands for ventilation and safety, including hospital wards, school classrooms, and nursing homes.
· Special environments prone to corrosion or high humidity, such as chemical plants, coastal buildings, and swimming pool areas.

Ss 304 Stainless Steel Wire Mesh Projector Screen/Insect Nets/Security Screen for Windows 2

SUS 304 Stainless Steel Insect Screen-S0001

Ss 304 Stainless Steel Wire Mesh Projector Screen/Insect Nets/Security Screen for Windows 3

SUS 304 Stainless Steel Insect Screen-S0002

Application:

Stainless steel security screen can resist the thieves and intruders, so it is used in the residences, hotels and other place for security.
Due to the anti-mosquitoes and flies feature, it can be used in the windows, doors, porches and patios to prevent the harmful insects.
Stainless steel security screen can resist the corrosion, rust and fire, it can be used in the harsh environments where is corrosive, dusty. It can also be used in the fire fighting accesses.
Another importance feature of the stainless steel security screen is bullet-proof, so it can be used in industry base, and other safety places.

Ss 304 Stainless Steel Wire Mesh Projector Screen/Insect Nets/Security Screen for Windows 4

SUS 304 Stainless Steel Insect Screen - S0003

Ss 304 Stainless Steel Wire Mesh Projector Screen/Insect Nets/Security Screen for Windows 5

SUS 304 Stainless Steel Insect Screen - S0004
