Corrosion Resistant Stainless Steel Welded Wire Mesh Panel for Ground

Large Image : Corrosion Resistant Stainless Steel Welded Wire Mesh Panel for Ground

Product Details:

Place of Origin:	CHINA
Brand Name:	QiJie
Certification:	ISO9001:2008, SGS, CE
Model Number:	01WWM

Payment & Shipping Terms:

Minimum Order Quantity:	50 rolls
Price:	USD9.90-USD45.90
Packaging Details:	Plastic film or water proof paper
Delivery Time:	10-25days
Payment Terms:	TT,LC,
Supply Ability:	1000 rolls/per day

Contact Now

Detailed Product Description

Material:	Carbon Steel Wire	Mesh Opening:	12 × 12, 20 × 20, 25 × 25, 12 × 25mm
Wire Diameter:	0.4mm - 1.5mm	Roll Width:	0.4m,0.5m,0.6m,0.8m, 1.0m, 1.25m, 1.5m, 2.0m
Roll Length:	15M,30M,50M Ect	Surface Treatment:	Hot Dipped Galvanized Or Electric Galvanized
Model Number:	Xx-01001	Application::	Fence Mesh
Email:	Devin@industrialmetalmesh.com	Whatsapp:	+8615369013183
Highlight:	stainless steel welded wire mesh , corrosion resistant wire mesh panel , ground welded wire mesh panel

Corrosion Resistant Stainless Steel Welded Wire Mesh Panel for Ground

Product Description:

Welded wire mesh, or welded wire fabric, or "weldmesh" is an electric fusion welded prefabricated joined grid consisting of a series of parallel longitudinal wires with accurate spacing welded to cross wires at the required spacing.
Machines used to produce the mesh must be with precise dimensional control. The product in considerable savings in time. labor and money.

Welded Wire Mesh is manufactured from high-quality low carbon steel wire and welded automatically through advanced welding equipment. It offers excellent corrosion resistance, uniform mesh openings, strong welding points and long service life.

It is widely used in:

·Construction Reinforcement
·Agriculture
·Animal Cages
·Security Fencing
·Industrial Protection
·nfrastructure Projects

Specification List of Wire Mesh Panel
Opening
In inch	In metric unit(mm)	Wire Diameter(mm)
1" x 1"	25.4mmX25.4mm	16mm,17mm,18mm,19mm,20mm,21mm
1-1/2" x 1-1/2"	38mm x 38mm	14mm,15mm,16mm,17mm,18mm,19mm
1" x 2"	25.4mm x 50.8mm	14mm,15mm,16mm
2" x 2"	50.8mm x 50.8mm	12mm,13mm,14mm,15mm,16mm
2" x 3"	50mmx70mm	2.0mm,2.5mm,1.65mm
3" x 3"	75mmx75mm	2.67mm,2.41mm,2.11mm
2" x 4"	50mmx100mm	2.11mm,2.5mm
4" x 4"	100mmx100mm	2.0mm,2.5mm
Technical Note: 1.Standard length: 1-8m; width: 0.5-3m 2.Special sizes available at request 3.Packing: in pallet. Custom packing available at request.

Welded Wire Plaster Wall Mesh

1,High Strength & Durability
Strong welded joints provide reliable reinforcement and extend the service life of concrete structures.
2,Improved Construction Efficiency
Prefabricated mesh panels reduce on-site labor, speed up installation, and ensure consistent quality.
3,Crack Resistance
Enhances tensile strength of concrete and effectively prevents cracking under load.
4,Cost-Effective
Minimizes material waste, lowers labor costs, and shortens project time.
5,Wide Applications
Suitable for residential, commercial, and infrastructure projects such as highways, bridges, tunnels, airports, and industrial buildings.
6,Customization Available
Mesh size, wire diameter, and panel dimensions can be tailored to meet specific project requirements.
7,Corrosion Resistance
Galvanized or coated options ensure long-term protection in harsh environments.

Applications:

Widely used in industry, agriculture, construction, transportation, mining, and other industries. Such as machine protective hoods, beasts and animal fences, window fences, channel fences, poultry cages, paper baskets, and decorations.

Welded Wire Plaster Wall Mesh

Qijie Wire Mesh MFG Co.,ltd is a professional manufacturer of fences, wire mesh products with more than 20 years experience. Welcome to visit our factory located in Anping city at any time!
