High-Quality Bto-22 Concertina Razor Barbed Wire Coil for Security Fencing in Nigeria Market

High-Quality Bto-22 Concertina Razor Barbed Wire Coil for Security Fencing in Nigeria Market
High-Quality Bto-22 Concertina Razor Barbed Wire Coil for Security Fencing in Nigeria Market High-Quality Bto-22 Concertina Razor Barbed Wire Coil for Security Fencing in Nigeria Market

Large Image :  High-Quality Bto-22 Concertina Razor Barbed Wire Coil for Security Fencing in Nigeria Market

Product Details:
Place of Origin: HeBei,China
Brand Name: QiJie
Certification: qijie
Model Number: qijie
Payment & Shipping Terms:
Minimum Order Quantity: 1 rolls
Price: Discuss
Packaging Details: Wooden carton
Delivery Time: within 7-30 days
Payment Terms: 30%TT in advance,Balance before loading
Supply Ability: 1500 Roll/Rolls per Week
Detailed Product Description
Material: Stainless Steel Wire, 316, 304, Plain Steel Galvanized Technique: Welded Mesh
Application: Screen, Protecting Mesh Hole Shape: Square Hole, Rectangule Hole
Normal Blade Type: BTO-22, BTO-30, CBT-60, CBT-65 Email: Devin@industrialmetalmesh.com
Whatsapp: +8615369013183
Highlight:

Bto-22 concertina razor barbed wire

,

Concertina razor wire for security fencing

,

Razor wire coil Nigeria market



High-Quality Bto-22 Concertina Razor Barbed Wire Coil for Security Fencing in Nigeria Market​

Razor wire is a highly formidable security barrier designed for maximum protection in environments requiring the highest levels of security and deterrence. Engineered to prevent unauthorized access, its exceptional defensive capability relies heavily on controlling the density of the barbs to guarantee maximum physical strength and rigidity. The most widely utilized specification is the standard BTO-22 blade profile, known for its sharp, threatening appearance and optimal piercing efficiency. To accommodate diverse security configurations and site layouts, this premium fencing material is fully customizable, offering a wide range of model variations, styles, and dimensions tailored to meet exact project specifications.


BTO-30 Blade Specifications

Blade Type Barb Thickness Barb Length Barb Width Barb Spacing Core Wire Diameter
BTO-30 0.5 ± 0.05 30.0 ± 1 18 ± 1 45 ± 2 2.5 ± 0.1



High-Quality Bto-22 Concertina Razor Barbed Wire Coil for Security Fencing in Nigeria Market





Concertina Flat Wrap Razor Wire Fencing Sizes and Specifications

Flat Wrap Razor Wire
Model BTO-30 CBT-60 CBT-65
Pattern BTO-30 CBT-60 CBT-65
Thickness 0.5mm+/-0.05mm 0.5mm+/-0.05mm 0.5mm+/-0.05mm
Core Wire Diameter 2.5mm+/-0.1mm 2.5mm+/-0.1mm 2.5mm+/-0.1mm
Blade Length 30mm+/-1mm 60mm+/-1mm 65mm+/-1mm
Blade Width 18mm+/-1mm 32mm+/-1mm 21mm+/-1mm
Blade Space 45mm+/-1mm 100mm+/-1mm 100mm+/-1mm
Coil Diameter 900/700/500/450mm 900/700/500/450mm 900/700/500/450mm
No. of Loops 34/41/53 34/41/53 34/41/53
Covering Length 8/10/13m 8/10/13m 8/10/13m
Coil Type Single Single Single



Diagram of Concertina Flat Wrap Razor Wire Fencing

bto30 razor wire
  Specification:
• Coil diameter: 1100 mm ±20 mm;
• Working diameter: ≥900 mm;
• 7 connection clips/points per coil;
• ≥100 turns;
• Main wire: 2.80–3.00 mm;
• Recommended stretched length: 20 m;
• Maximum stretched length: 25 m;
• Coil weight: 30–35 kg;
• Razor strip: carbon galvanized steel, EN 10346;
• Blade thickness: 0.50–0.55 mm;
• Blade length: 16–17 mm
• Razor strip width: ≥19 mm
• Central strip width: ≥7.5 mm
• Tooth pitch: ≤30 mm
• Zinc coating on razor strip: ≥140 g/m²
• Main wire tensile strength: ≥1600 N/mm²
• Zinc coating on main wire: ≥140 g/m²


Razor barbed wire packages:
1. Waterproof paper and woven bag, and then tied by steel strip.
2. Carton (Mostly for stainless steel concertina wire).
3. Fumigation Wooden Pallet.
4. Customized.


Product specification



# Parameter Required value
1 Coil diameter (transport position), mm 1050-1150
2 Coil diameter (deployed / working position), mm 875-925
3 Quantity of connection points (clips) per loop Not less than 7
4 Quantity of loops per coil, pcs Not less than 90
5 Core wire diameter (A), mm 2.5-3.0
6 Extended / stretching length of one coil, m 19.0-21.0
7 Blade shape of the barbed strip Aggressive profile (crimped around the core wire)
8 Coil / bobbin weight, kg Up to 35
9 Razor tape thickness (B), mm 0.45-0.55
10 Razor blade length (C), mm 16.0-22.0
11 Razor tape width (D), mm 14.0-17.0
12 Razor tooth pitch (E), mm 30.0-40.0
13 Maximum angle of razor tooth, deg. Not more than 45
14 Core wire material High-carbon steel wire
15 Core wire tensile strength, N/mm² (MPa) Not less than 1510
16 Zinc coating mass on core wire, g/m² Not less than 80
17 Razor tape material Carbon galvanized steel strip
18 Zinc coating mass on razor tape (double side), g/m² Not less than 140
19 Connecting brackets (clips) material Hot-dip galvanized steel, thickness ≥ 1.5 mm, width ≥ 10 mm
20 Zinc coating mass on clips, g/m² Not less than 140
21 Clip tensile strength at break (opening force), N Not less than 480



Application:


Application of Concertina Flat Wrap Razor Wire Fencing

  •   Facilities

  • Industrial and Construction Sites

  • Laboratories and Research Facilities

  • Prisons and Correctional Facilities like Prison Fence Wire

razor wire
Application of concertina razor barbed wire
Razor Barbed Wire is widely used in airport , prison, government, bank, and also in living wall, personal house, villatic wall, window, autobahn, railway and border of the fence.

Packing of concertina razor barbed wire
compression rolls, water-proof paper inside, woven bag outside or in carton
