Product Details:
Payment & Shipping Terms:
|
| Type: | Fencing,Trellis & Gates,Welded Mesh | Feature: | Easily Assembled,Eco Friendly,Waterproof,Rodent Proof |
|---|---|---|---|
| Metal Type: | Iron,Iron Or Galvanized | Frame Finishing: | PVC Coated |
| Frame Material: | Metal | Material: | Galvanized Iron Wire,Low Carbon Steel Wire |
| Color: | White,black,Green,blue,red | Surface Treatment: | Galvanized+PVC Coated |
| Application: | Construction Wire Mesh,Fence Mesh,Garden,Residential | Product Name: | Welded Wire Mesh Fence Panel |
| Mesh Size: | 50x100mm,75x150mm,200mm*50mm / 150mm*50mm/100mm*50mm,50x200 Mm | Usage: | Protection,Garden Decoration |
| Width: | 1500mm ~ 3000mm | Length: | 2m/2.5m Or According To Your Request |
| Height: | 1030mm / 1230mm / 1430mm / 1630mm / 1830mm / 2030mm / 2230mm | Wire Diameter: | 3-8mm,5/6/5mm |
| Wire Gauge: | 2.0-4.0mm | ||
| High Light: | galvanized curved metal garden fencing,3d curved metal garden fencing,corrosion resistance curved metal garden fencing |
||
50x100mm Galvanized 3d Curved Metal Garden Fencing Corrosion Resistance
3D Curved Fence is a fence designed with a curved shape to create a three-dimensional appearance. These fences are usually made of materials such as metal, wood or vinyl and can be used for a variety of purposes such as privacy, security or landscaping. The curved shape adds a unique and interesting character to the fence, making it an attractive addition to any property. The 3D curved fence is designed to follow the contours of your landscape naturally, making it a great choice for uneven terrain.
3d curved welded wire mesh fence is a type of welded wire mesh which has V-shaped strengthen bending curves. It is made of high quality low carbon steel wire, galvanized steel wire,metal column connected. The surface treatment of Triangle bend fence includes: hot-dipped galvanized, PVC coated, powder coated, polyester coated.
Material: High quality low carbon steel wire, galvanized iron wire etc.
Manufacturing process: spot welding,Gas shielded welding.
Finishing: Galvanized, Powder spraying, PVC coated, Vinyl coated.
The panels and posts are jointed together with bolts or rivets, using the steel flat bar, or special steel clamps, all nuts are self-locking. This also can be designed as the special clients requests.
Specification:
| Mesh Size | Wire Diameter | Panel Height | Panel Width | Bending No. | Common Color | Surface Treatment |
50*100mm 50*200mm 55*100mm 55*200mm |
4mm 5mm |
830mm | 2m 2.2m 2.4m 2.8m 3m |
2 | Green RAL 6005 Grey RAL 7016 Brown RAL 8019 Black RAL 9005 White RAL 9010 |
1.Hot dipped galvanized after black wire welded 2.PVC coated after galvanized wire welded 3.PE coated after galvanized wire welded 4.Powder coated after galvanized wire welded |
| 1030mm | 2 | |||||
| 1230mm | 2 | |||||
| 1530mm | 3 | |||||
| 1830mm | 4 | |||||
| 2030mm | 4 | |||||
| 2230mm | 4 | |||||
| 2430mm | 4 |
The 3d curved Fence can be used to
- Airports
- Railway
- School
- Commercial site
- House hold
- landscape
