Galvanized Pvc Coated Barbed Tape Concertina Wire Stainless Steel Cbt-60 Cbt-65

Large Image : Galvanized Pvc Coated Barbed Tape Concertina Wire Stainless Steel Cbt-60 Cbt-65

Product Details:

Place of Origin:	China
Brand Name:	Qijie
Certification:	ISO9001
Model Number:	QJ-R001

Payment & Shipping Terms:

Minimum Order Quantity:	100 rolls
Price:	discuss
Packaging Details:	Woven bag outside,carton box etc
Delivery Time:	15-20 days
Payment Terms:	30%TT in advance, Balance before loading
Supply Ability:	100 tons per week

Contact Now

Detailed Product Description

Type:	Barbed Wire Coil	Barbed Model:	Bto-22, Cbt-65
Specification:	7-16m	Coil Outside Diameter:	960mm
Email:	Devin@industrialmetalmesh.com	Whatsapp:	+8615369013183
Highlight:	cbt-60 barbed tape concertina wire , pvc coated barbed tape concertina wire , cbt-65 concertina razor wire

Product Description

Cross Razor barbed wire

1. Razor wire in hot-dipped galvanized sheet is economic cost compared with stainless steel.

2. Specifications:
Barbed Tape Concertina (BTC); Barbed Tape Obstacle (BTO);

3. Standard materials:
Hot-dipped galvanized steel sheet and wire, SS 304, 430 and 316.

4. Specifications are available on requests.
Diameter: 2.5mm
Sheet: 0.5 and 0.6 mm
Razor length: 10 to 65mm
Razor width: 13 to 32mm
Razor spacing: 26 to 100mm
Standard length per coil: 7 to 16m

5. There are many ways to use Razor barbed wire; It can be widely used in industry, agriculture and especially in military security.

Model	Razor Thickness	Diameter of Core Wire	Razor Length	Razor Width	Space between Razors
BTO-12	0.5± 0.05	2.5± 0.1	10± 1	13± 1	26± 1
BTO-18	0.5± 0.05	2.5± 0.1	15± 1	15± 1	33± 1
BTO-22	0.5± 0.05	2.5± 0.1	22± 1	15± 1	34± 1
CBT-65	0.6± 0.05	2.5± 0.1	65± 2	21± 1	100± 2

Outside Diameter	Cycles	Standard Coverage Length	Production Form	Remarks
450mm	33	8M	CBT-65	Single coil
500mm	41	10M	CBT-65	Single coil
700mm	41	10M	CBT-65	Single coil
960mm	53	13M	CBT-65	Single coil
500mm	102	16M	BTO-10.15.22	Cross type
600mm	86	14M	BTO-10.15.22	Cross type
700mm	72	12M	BTO-10.15.22	Cross type
800mm	64	10M	BTO-10.15.22	Cross type
960mm	52	9M	BTO-10.15.22	Cross type
