Bto22 Razor Concertina Coil 450mm Diameter Barbed

Large Image : Bto22 Razor Concertina Coil 450mm Diameter Barbed

Product Details:

Place of Origin:	China
Brand Name:	Qijie
Certification:	ISO9001
Model Number:	QJ-R001

Payment & Shipping Terms:

Minimum Order Quantity:	100 rolls
Price:	discuss
Packaging Details:	Woven bag outside,carton box etc
Delivery Time:	15-20 days
Payment Terms:	30%TT in advance, Balance before loading
Supply Ability:	100 tons per week

Contact Now

Detailed Product Description

Material:	Galvanized Iron Wire	Cross Type:	Single Or Cross
Coil Outside Diameter:	450mm	Wire Gauge:	Bto22 Bto30 Cbt65
Razor Barbed Type:	Cross Razor	Finish:	Hot Dipped Galvanized
Application:	Protecting Mesh, Fence Mesh	Blade Type:	Bto-10, Bto-22, Bto-30, Cbt-60, Cbt-65
Coil Diameter:	300-1000mm	Specification:	Coil Diameter And Razor Type Can Made As Request
Email:	Devin@industrialmetalmesh.com	Whatsapp:	+8615369013183
Highlight:	bto22 razor concertina coil , barbed razor concertina coil , bto22 concertina barbed wire

Product Description

Razor barbed wire fencing is usually made of galvanized steel blade or stainless steel blade. Two pieces of stainless steel razor wire or zinc-coated razor wire can be bounded together by clips to make it stronger. The spiral intersecting barbed wire presents an intersecting shape after opening with beautiful outlook and practical property.

1. Material:
(1)Core wire material: Galvanized wire and stainless steel wire.
(2)Blade material: Galvanized sheet and stainless steel sheet.

2. Specification:
1. Razor thickness: 0.5mm
2. Wire diameter: 2.5mm
3. Razor width: 15 mm
4. Razor length: 22 mm
5. Barb spacing: 26mm--100mm
6. Outside diameter of roll: 600 mm
7. Number of loops: 33--102
8. Standard spreading length per roll: 8m --16m
9. Razor barbed type: Cross type
10. Packing: Compression rolls, water-proof paper inside, woven bag outside or in carton

3. Features: Razor barbed wire is also named Tape Wire, Razor Tape Wire, Barbed Tape or Barbed Tape Wire. It can be installed to achieve the result of frightening and stopping to the aggressive perimeter intruders, with piecing and cutting razor blades mounted at the top of the wall, also the special designs making climbing and touching extremely difficult. The wire an d strip are galvanized to prevent corrosion.

4. Application:
Razor barbed wire is widely used by in military field, prisons, detention houses, government buildings and other national security facilities; It is also used as fence for cottage and society fence, and other private buildings.

Barbed Tape Wire Specification
Outside Diameter	No. of Loops	Standard Length per Coil	Type	Notes
450mm	33	7-8M	CBT-60.65	Single coil
500mm	56	12-13M	CBT-60.65	Single coil
700mm	56	13-14M	CBT-60.65	Single coil
960mm	56	14-15M	CBT-60.65	Single coil
450mm	56	8-9M (3 CLIPS)	BTO-10.12.18.22.28.30	Cross type
500mm	56	9-10M (3 CLIPS)	BTO-10.12.18.22.28.30	Cross type
600mm	56	10-11M (3 CLIPS)	BTO-10.12.18.22.28.30	Cross type
600mm	56	8-10M (5 CLIPS)	BTO-10.12.18.22.28.30	Cross type
700mm	56	10-12M (5 CLIPS)	BTO-10.12.18.22.28.30	Cross type
800mm	56	11-13M (5 CLIPS)	BTO-10.12.18.22.28.30	Cross type
900mm	56	12-14M (5 CLIPS)	BTO-10.12.18.22.28.30	Cross type
960mm	56	13-15M (5 CLIPS)	BTO-10.12.18.22.28.30	Cross type
980mm	56	14-16M (5 CLIPS)	BTO-10.12.18.22.28.30	Cross type
